Mini contactor relays, contactor relays
2010 CA08103002Z-EN
5/99
Magnet systems
Voltage tolerance
AC operated
Single-voltage coil 50 Hz and dual-
voltage coil 50 Hz, 60 Hz
Pick-up x Uc 0.8…1.1 – 0.8…1.1 –
Dual-frequency coil 50/60 Hz Pick-up x Uc 0.8…1.1 – 0.85…1.1 –
DC operated1)
Starting voltage Pick-up x Uc 0.8…1.1 – 0.85…1.3 –
At 24 V: without auxiliary contact
module (40 °C)
Pick-up x Uc 0.7 - 1.3 – 0.7 - 1.3 –
Power consumption
50 Hz Pick-up VA 24 – 25 –
50 Hz Sealing VA 3.4 – 4.6 –
50 Hz Sealing W 1.2 – 1.3 –
60 Hz Pick-up VA 30 – 25 –
60 Hz Sealing VA 4.4 – 4.6 –
60 Hz Sealing W 1.4 – 1.3 –
50/60 Hz Pick-up VA 27
25
– 30
29
–
50/60 Hz Sealing VA 4.2
3.3
– 5.4
3.9
–
50/60 Hz Sealing W 1.4
1.2
– 1.6
1.1
–
DC operated Pick-up=
sealing
W 3 – 2.6 –
Duty factor % DF 100 – 100 –
Changeover times at 100 % Uc (recommended
values)
AC operated closing delay ms 15 - 21 – 14 - 21 –
AC operated normally open contact opening
delay
ms 9 - 18 – 8 - 18 –
AC operated with auxiliary contact module,
max. closing delay
ms – – 45 45
DC operated closing delay ms 31 – 26 - 35 –
DC operated normally open contact opening
delay
ms 12 – 15 - 25 –
DC operated with auxiliary contact module,
max. closing delay
ms – – 70 70
Notes 1) Smoothed DC, three-phase bridge rectifier or smoothed two-phase bridge rectifier
DILA DILA…XHI DILER DILE…
DILER, DILA
