Lamps & Lighting Electronics Catalogue 2014

13 / 272

>
A nium LED display modules 424 Well and serve-over
C1
A3
A1 B1
Dim. A1 A3 B1 C1
no. nom. nom. nom. nom.
1 900 930 34 22
2 250 280 34 22
3 1150 1180 34 22
Lighting Food. Brightening Faces.
Philips LED lighting for refrigeration cases
is a sustainable and energy-e cient way to
create an enjoyable shopping experience
for customers – while at the same time
supporting retailers’ brand values. LDM424
modules can be used for well counters
(under combined cabinets) or serve-over
counters. Thanks to their compact design, the
modules can be aesthetically integrated in the
cabinet design. The modules’ unique optical
system directs the light in such a way that the
products in the well or serve-over counter
are presented uniformly, while reducing glare
and dark spots. Our LEDs have minimal
output degradation and color shift, so the
light remains consistent throughout their
long service life. Simply an ideal solution for
high-quality display lighting without flicker or
color di erences. Mounting accessories and
power driver are available separately.
Product Benefits
•Excellent Total Cost of Ownership with
attractive payback times.
•Improved visibility and presentation of
the fresh food in the open well or serve-
over counter; uniform light distribution
throughout the entire cabinet.
•Virtually maintenance-free throughout the
lifetime of the cooler cabinets, since the
LEDs have a long lifetime of 50,000 hours
with excellent lumen maintenance.
Product Features
•The range includes Vision-plus for high
lighting levels (1,100 lux); Value-plus for
regular lighting levels (750 lux).
•Energy savings up to 80%
•Superb optical features; wide symmetrical
140º
•Products are dimmable
•5-year Philips warranty for the modules in
combination with the Philips LED power
driver
Application
•For well and serve-over lighting in freezers
and coolers
•Ties in perfectly with the current trend
for closed wells with glass tops to prevent
energy wastage
Type Wattage Colour
Rende-
ring
Index
Correlated
Colour
Temperature
Life to 70%
lumen
maintenance
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(W) (Ra) (°) (K) (h)
Value-plus LDM424 900mm(35") NW 7 75 120 4,100 50,000 1 1NO / 6 6 LDM424VA900NW 249030 00
Vision-plus LDM424 250mm(10") WW 8 85 120 3,000 50,000 2 1NO / 6 6 LDM424VI250WW 249115 00
Vision-plus LDM424 250mm(10") NW 8 85 120 4,100 50,000 2 1NO / 6 6 LDM424VI250NW 249078 00
Value-plus LDM424 250mm(10") NW 8 75 120 5,600 50,000 1 1NO / 6 6 LDM424VA900CW 248972 00
Value-plus LDM424 1150mm(45") NW 9 75 120 4,100 50,000 3 1NO / 6 6 LDM424VA1150NW 249177 00
Vision-plus LDM424 900mm(35") NW 17 85 120 4,100 50,000 1 1NO / 6 6 LDM424VI900NW 248934 00
Value-plus LDM424 1150mm(45") CW 17 75 120 5,600 50,000 3 1NO / 6 6 LDM424VA1150CW 245674 00
Vision-plus LDM424 1150mm(45") NW 20 85 120 4,100 50,000 3 1NO / 6 6 LDM424VI1150NW 245636 00
Vision-plus LDM424 900mm(35") WW 21 85 120 3,000 50,000 1 1NO / 6 6 LDM424VI900WW 248958 00
Vision-plus LDM424 1150mm(45") WW 26 85 120 3,000 50,000 3 1NO / 6 6 LDM424VI1150WW 245650 00
Accessories for A nium LED display modules
Lighting food. Brightening faces.
To facilitate installation of the A nium LED
display modules, we have designed di erent
mounting profiles. These provide equipment
manufacturers with tailor-made solutions to
meet the specific requirements of all cabinets.
The glare-free versions prevent annoying glare
to ensure a pleasant shopping experience for
customers.
Furthermore, a separate connector (LS SB)
and a connector tool are available for safe
and easy connection of the wiring inside the
refrigerator.
Product Benefits
•Easy installation
•Lighting directed precisely at the merchand-
ise, without glare
•Aesthetic integration of modules into
cabinets and door frames
Product Features
•Removal of sharp metal edges which could
cause injury to shoppers
•Easy click-in system to connect the module
to the mounting profiles
•Special glare-free profile
•Wide range of mounting profiles to suit the
di erent cabinets
Application
•Commercial freezers and coolers
System
•For horizontal lighting: mounting profile 10°,
mounting profile 45°, mounting profile
•For vertical lighting: glare-free mounting
profile center and side, mounting profile
