Lamps & Lighting Electronics Catalogue 2014

10 / 272

>
A nium LED display modules 400 Full-height glass doors
C1
A3
A1 B1
Dim. A1 A3 B1 C1
no. nom. nom. nom. nom.
1 1500 1510 34 22
2 1700 1710 34 22
Lighting food. Brightening faces.
Philips LED lighting for refrigeration cases
is a sustainable and energy-e cient way to
create an enjoyable shopping experience
for customers – while at the same time
supporting retailers’ brand values. LDM400
modules can be vertically integrated in
full-height glass-door refrigeration cabinets.
Thanks to their compact design, the modules
can be aesthetically integrated in the door
frame of the cabinet. The modules’ unique
optical system directs the light in such a way
that the products on display are presented
uniformly, while reducing glare and dark spots.
Our LEDs have minimal output degradation
and color shift, so the light remains consistent
throughout their long service life. Simply an
ideal solution for high-quality display lighting
without flicker or color di erences. Mounting
accessories and power driver are available
separately.
Product Benefits
•Excellent Total Cost of Ownership with
attractive payback times.
•Improved visibility and presentation of
the fresh food on display; uniform light
distribution throughout the entire cabinet.
•Virtually maintenance-free throughout the
lifetime of the cabinets, since the LEDs have
a long lifetime of 50,000 hours with excellent
lumen maintenance.
Product Features
•The range includes Vision-plus for high light-
ing levels (1,100 lux); Value-plus for regular
lighting levels (750 lux). The Center module
is used for for vertical light distribution in
two directions. The Side module for vertical
light distribution in one direction.
•Energy savings up to 80%
•Superb optical features; Side asymmetrical
15º, Center 15º both directions
•Products are dimmable
•5-year Philips warranty for the modules in
combination with the Philips LED power
driver.
Application
•Full-height glass doors and mullions (vertical
integration)
•Especially suitable for closed coolers with
glass doors to prevent energy wastage
Type Wattage Colour
Rende-
ring
Index
Correlated
Colour
Temperature
Life to 70%
lumen
maintenance
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order Code Ordering
number
8718291...
(W) (Ra ) (°) (K) (h)
Value-plus LDM400 1500mm(59") CW 9 75 15 5,600 50,000 1 1NO / 6 6 LDM400VA1500CW 247630 00
Value-plus LDM400 1500mm(59") NW 12 75 15 4,100 50,000 1 1NO / 6 6 LDM400VA1500NW 247678 00
Value-plus LDM400 1700mm(67") CW 12 75 15 5,600 50,000 2 1NO / 6 6 LDM400VA1700CW 246572 00
Value-plus LDM400 1700mm(67") NW 14 75 15 4,100 50,000 2 1NO / 6 6 LDM400VA1700NW 247371 00
Value-plus LDM400 1500mm(59") WW 15 85 15 3,000 50,000 1 1NO / 6 6 LDM400VA1500WW 243441 00
Vision-plus LDM400 1500mm(59") NW 18 75 15 4,100 50,000 2 1NO / 6 6 LDM400VI1500NWC 246497 00
Vision-plus LDM400 1700mm(67") NW 21 75 15 4,100 50,000 2 1NO / 6 6 LDM400VI1700NWC 246435 00
Vision-plus LDM400 1500mm(59") WW 22 85 15 3,000 50,000 1 1NO / 6 6 LDM400VI1500WWC 243403 00
Philips Lamps and Lighting Electronic Catalogue 2014 10
01
LED
