12 / 272
LED and Systems
>
LED Display Lighting SystemsType
Wattage Colour
Rende-
ring
Index
Correlated
Colour
Temperature
Life to 70%
lumen
maintenance
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(W)
(R
a
) (°)
(K)
(h)
Value-plus LDM421 600mm(24") NW 9
85 40
4,000
50,000
1 1NO / 6 6
LDM421VA600NW
244448
00
Value-plus LDM421 1200mm(47") NW 13
85 40
4,000
50,000
2 1NO / 6 6
LDM421VA850NW
244363
00
Value-plus LDM421 850mm(33") WW 15
85 40
3,000
50,000
2 1NO / 6 6
LDM421VA850WW
244387
00
Vision-plus LDM421 600mm(24") NW 15
85 40
4,000
50,000
1 1NO / 6 6
LDM421VI600NW
246152
00
Vision-plus LDM421 600mm(24") WW 17
85 40
3,000
50,000
1 1NO / 6 6
LDM421VI600WW
246176
00
Value-plus LDM421 1200mm(47") NW 18
85 40
4,000
50,000
3 1NO / 6 6
LDM421VA1200NW
243700
00
Vision-plus LDM421 850mm(33") NW 20
85 40
4,000
50,000
2 1NO / 6 6
LDM421VI850NW
246114
00
Vision-plus LDM421 850mm(33") WW 22
85 40
3,000
50,000
2 1NO / 6 6
LDM421VI850WW
246138
00
Value-plus LDM421 1200mm(47") WW 22
85 40
3,000
50,000
3 1NO / 6 6
LDM421VA1200WW
243748
00
Vision-plus LDM421 1200mm(47") NW 28
85 40
3,000
50,000
3 1NO / 6 6
LDM421VI1200WW
243656
00
Vision-plus LDM421 1200mm(47") NW 28
85 40
4,000
50,000
3 1NO / 6 6
LDM421VI1200NW
243632
00
A nium LED display modules 422 Canopies
C1
A3
A1
B1
Dim.
A1
A3
B1
C1
no.
nom.
nom.
nom.
nom.
1
600
610
34
22
2
850
860
34
22
3
1200
1210
34
22
Lighting food. Brightening faces.
Philips LED lighting for refrigeration cases
is a sustainable and energy-e cient way to
create an enjoyable shopping experience
for customers – while at the same time
supporting retailers’ brand values. LDM 422
modules can be integrated in the canopy of a
refrigeration case. Thanks to their compact
design, the modules can be aesthetically
integrated in the cabinet design.
The modules’ unique optical system directs
the light in such a way that the products
on display are presented uniformly, while
reducing glare and dark spots. Our LEDs have
minimal output degradation and color shift, so
the light remains consistent throughout their
long service life. Simply an ideal solution for
high-quality display lighting without flicker or
color di erences. Mounting accessories and
power driver are available separately.
Product Benefits
•Excellent Total Cost of Ownership with
attractive payback times
•Improved visibility and presentation of
the fresh food on display; uniform light
distribution throughout the entire cabinet
with extra emphasis at eye level and fewer
dark spots
•Virtually maintenance-free throughout the
lifetime of the cooler cabinets, since the
LEDs have a long lifetime of 50,000 hours
with excellent lumen maintenance
Product Features
•The range includes Vision-plus for high
lighting levels (1,100 lux) and Value-plus for
regular lighting levels (750 lux).
•Energy savings of up to 50%
•Superb optical features: mid-asymmetrical
80º
•Products are dimmable
•5-year Philips warranty on the modules in
combination with the Philips LED power
driver
Application
•Canopy lighting in freezer and coolers
•Especially suitable for closed coolers with
glass doors to prevent energy wastage
Type
Wattage Colour
Rende-
ring
Index
Correlated
Colour
Temperature
Life to 70%
lumen
maintenance
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(W)
(R
a
) (°)
(K)
(h)
Value-plus LDM422 600mm(24") NW 9
85 80
4,000
50,000
1 1NO / 6 6
LDM422VA600NW
245599
00
Value-plus LDM422 600mm(24") WW 11
85 80
3,000
50,000
1 1NO / 6 6
LDM422VA600WW
245612
00
Value-plus LDM422 850mm(33") NW 13
85 80
4,000
50,000
2 1NO / 6 6
LDM422VA850NW
245551
00
Value-plus LDM422 850mm(33") WW 15
85 80
3,000
50,000
2 1NO / 6 6
LDM422VA850WW
245575
00
Value-plus LDM422 1200mm(47") NW 18
85 80
4,000
50,000
3 1NO / 6 6
LDM422VA1200NW
245414
00
Vision-plus LDM422 850mm(33") NW 20
85 80
4,000
50,000
2 1NO / 6 6
LDM422VI850NW
245452
00
Vision-plus LDM422 850mm(33") WW 22
85 80
3,000
50,000
2 1NO / 6 6
LDM422VI850WW
245537
00
Value-plus LDM422 1200mm(47") WW 22
85 80
3,000
50,000
3 1NO / 6 6
LDM422VA1200WW
245438
00
Vision-plus LDM422 1200mm(47") NW 28
85 80
4,000
50,000
3 1NO / 6 6
LDM422VI1200NW
245377
00
Vision-plus LDM422 1200mm(47") WW 33
85 80
3,000
50,000
3 1NO / 6 6
LDM422VI1200WW
245391
00
Philips Lamps and Lighting Electronic Catalogue 2014
12
01
LED
