MASTER LEDtube SA1 Gen2
A1
A2
A3
D2 D1
Dim. A1 A2 A3 D1 D2
no. nom. nom. nom. nom. nom.
1 588.5 595.5 602.5 28 25.68
2 893.5 900.5 907.5 28 25.68
3 1198.0 1205.0 1212.0 28 25.68
Lighting food. Brightening faces.
MASTER LEDtube SA1 is an extremely e ect-
ive energy-saving alternative to fluorescent
lamps. Designed for use in professional
coolers, the SA1 version can be installed
below the canopy. This state-of-the-art LED
solution enhances the visual impression of
the merchandise on display while at the same
time minimizing glare for passing customers.
The improved rotating end-cap makes it
even easier to direct the light precisely at
the merchandise. The product’s long lifetime
and excellent lumen maintenance minimize
the hassle of re-lamping, while reducing
maintenance costs. Thanks to MASTER
LEDtube’s refined design it is now easy to
upgrade your cooler to LED lighting.
Benefits
•Energy savings of more than 54% compared
to fluorescent lamps
•Uniform light distribution enhances the
presentation of the merchandise on display
•New green image thanks to Philips
LED technology, no mercury, improved
sustainability
Product Features
•High-tech optical system creates optimum
light uniformity with maximum e cacy and
minimum glare
•Rotating end-cap ensures easy aiming for the
best lighting result
•Fool-proof design ensures safety even in
the event of mistakes in the installation
process; compliant with (inter)national safety
requirements
•Embedded electrical driver for easy
installation
•Compatible with standard G13 lamp holders
Applications
•Cooler canopies
System
The SA1 version is part of the MASTER
LEDtube SA range. Designed for use in
coolers, the SA1 version can be installed
below the canopy, and the SA2 under the
shelves, to create a total solution.
Warning
•When replacing fluorescent lamps with
MASTER LEDtube SA1, the electrical
installation has to be changed. Please contact
Philips for advice.
Type Colour
Rende-
ring
Index
Correlated
Colour
Temperature
Life to 70%
lumen
maintenance
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(Ra) (°) (K) (h)
MASTER LEDtube SA1 600mm 800lm 830 G13 85 180 3,000 40,000 1 1CT / 10 10 TLED600SA1830 25204700
MASTER LEDtube SA1 600mm 800lm 840 G13 85 180 4,000 40,000 1 1CT / 10 10 TLED600SA1840 25206100
MASTER LEDtube SA1 600mm 800lm 856 G13 85 180 5,600 40,000 1 1CT / 10 10 TLED600SA1856 25208500
MASTER LEDtube SA1 900mm 1150lm 830 G13 85 180 3,000 40,000 2 1CT / 10 10 TLED900SA1830 25210800
MASTER LEDtube SA1 900mm 1150lm 840 G13 85 180 4,000 40,000 2 1CT / 10 10 TLED900SA1840 25212200
MASTER LEDtube SA1 900mm 1150lm 856 G13 85 180 5,600 40,000 2 1CT / 10 10 TLED900SA1856 25214600
MASTER LEDtube SA1 1200mm 1600lm 830 G13 85 180 3,000 40,000 3 1CT / 10 10 TLED1200SA1830 25216000
MASTER LEDtube SA1 1200mm 1600lm 840 G13 85 180 4,000 40,000 3 1CT / 10 10 TLED1200SA1840 25218400
MASTER LEDtube SA1 1200mm 1600lm 856 G13 85 180 5,600 40,000 3 1CT / 10 10 TLED1200SA1856 25220700
