Lamps & Lighting Electronics Catalogue 2014

11 / 272

>
A nium LED display modules 410 Half-height glass doors
C1
A3
A1 B1
Dim. A1 A3 B1 C1
no. nom. nom. nom. nom.
1 950 960 34 22
2 750 760 34 22
Lighting food. Brightening faces.
Philips LED lighting for refrigeration cases
is a sustainable and energy-e cient way to
create an enjoyable shopping experience
for customers – while at the same time
supporting retailers’ brand values. LDM410
modules can be vertically integrated in
half-height glass-door refrigeration cabinets.
Thanks to their compact design, the modules
can be aesthetically integrated in the door
frame cabinet design. The modules’ unique
optical system directs the light in such a way
that the products on display are presented
uniformly, while reducing glare and dark spots.
Our LEDs have minimal output degradation
and color shift, so the light remains consistent
throughout their long service life. Simply an
ideal solution for high-quality display lighting
without flicker or color di erences. Mounting
accessories and power driver are available
separately.
Product Benefits
•Excellent Total Cost of Ownership with
attractive payback times.
•Improved visibility and presentation of
the fresh food on display; uniform light
distribution throughout the entire cabinet.
•Virtually maintenance-free throughout the
lifetime of the cabinets, since the LEDs have
a long lifetime of 50,000 hours with excellent
lumen maintenance.
Product Features
•The range includes Vision-plus for high light-
ing levels (1,100 lux); Value-plus for regular
lighting levels (750 lux). The Center module
is used for for vertical light distribution in
two directions. The Side module for vertical
light distribution in one direction.
•Energy savings up to 80%
•Superb optical features; Side asymmetrical
15º, Center 15º both directions
•Products are dimmable
•5-year Philips warranty for the modules in
combination with the Philips LED power
driver.
Application
•Half-height glass doors and mullions (vertical
integration).
•Especially suitable for closed coolers with
glass doors to prevent energy wastage
Type Wattage Colour
Rende-
ring
Index
Correlated
Colour
Temperature
Life to 70%
lumen
maintenance
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(W) (Ra) (°) (K) (h)
Value-plus LDM410 950mm(37") CW 8 75 15 5,600 50,000 1 1NO / 6 6 LDM410VA950CW 24809500
Value-plus LDM410 750mm(30") CW 8 75 15 5,600 50,000 2 1NO / 6 6 LDM410VA750CW 24848400
Value-plus LDM410 750mm(30") NW 9 75 15 4,100 50,000 2 1NO / 6 6 LDM410VA750NW 24852100
Value-plus LDM410 950mm(37") NW 10 75 15 4,100 50,000 1 1NO / 6 6 LDM410VA950NW 24829300
A nium LED display modules 421 Island freezers
C1
A3
A1 B1
Dim. A1 A3 B1 C1
no. nom. nom. nom. nom.
1 600 610 34 22
2 850 860 34 22
3 1150 1160 34 22
Lighting food. Brightening faces.
Philips LED lighting for refrigeration cases
is a sustainable and energy-e cient way to
create an enjoyable shopping experience
for customers – while at the same time
supporting retailers’ brand values. LDM421
modules can be used for island freezer
lighting. Thanks to their compact design,
the modules can be aesthetically integrated
in the cabinet design. The modules’ unique
optical system directs the light in such a way
that the products in the freezer are presented
uniformly.
Our LEDs have minimal output degradation
and color shift, so the light remains consistent
throughout their long service life. Simply an
ideal solution for high-quality display lighting
without flicker or color di erences Mounting
accessories and power driver are available
separately.
Product Benefits
•Excellent Total Cost of Ownership with
attractive payback times.
•Improved visibility and presentation of the
merchandise in the island freezer; uniform
light distribution throughout the entire
cabinet.
•Virtually maintenance-free throughout the
lifetime of the cooler cabinets, since the
LEDs have a long lifetime of 50,000 hours
with excellent lumen maintenance.
Product Features
•The range includes Vision-plus for high
lighting levels (1,100 lux); Value-plus for
regular lighting levels (750 lux)
•Energy savings up to 60%
•Superb optical features; narrow symmetrical
40º
•Products are dimmable
•5-year Philips warranty for the modules in
combination with the Philips LED power
driver.
Application
•Island freezer lighting
•Especially suitable for closed coolers with
glass doors to prevent energy wastage
Philips Lamps and Lighting Electronic Catalogue 2014 11
01
LED
