LED and Systems
>
LED Display Lighting SystemsInteGrade LED engine system
A
C
B1
Dim.
A
B1
C
no.
max.
nom.
max.
1
575
18.5
11
2
140
18.5
11
The perfect fit
The InteGrade LED engine system is a
sustainable and energy-e cient way to
create an enjoyable shopping experience.
The system can be used for shelf and linear
accent lighting. With the dedicated InteGrade
connectors it is easy to create longer light-
lines. Thanks to the system’s compact
dimensions, it can be aesthetically integrated
into the store interior, below or inside shelves
and refrigerated cabinets.
A unique asymmetrical optics direct the light
where you want it, thus making optimum
use of the light and energy. The products or
background you want lit will be presented
uniformly, with reduced glare and dark
spots. Our LEDs have minimal output
degradation and colour shift, so the light
remains consistent throughout their long
lifetime. InteGrade LED is an ideal solution for
high-quality lighting without flicker or colour
di erences. Mounting accessories, cables and
LED power driver are available separately.
Product Benefits
•Excellent Total Cost of Ownership with
attractive payback times
•Aesthetic integration of LED lighting; enables
seamless light-lines with uniform light
distribution
•Easy to install
Product features
•Energy savings of up to 65% (10 W
compared to a 28 W TL5 system)
•Superb asymmetrical optics
•InteGrade cabling allows connection to own
connector system
•5-year Philips warranty (InteGrade LED
engine in combination with
Philips cables and Philips LED power driver)
Applications
•Shelf and linear accent lighting in su-
permarkets, refrigerated cabinets, retail
environments, libraries, museums
System
•The InteGrade LED engine system consists
of di erent components which are designed
and marketed together, as we believe
good system design is crucial to e ective
functioning of the system, and it also
facilitates an easy design-in
•The system includes InteGrade LED engines,
Xitanium drivers and mounting accessories.
They facilitate hassle-free and reliable
installation.
Type
Colour
Rendering
Index
Correlated
Colour
Temperature
Life to 70%
lumen
maintenance
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(R
a
)
(K)
(h)
InteGrade engine vision 575mm(23") 830
85
3,000
50,000
1
1NO / 24 24
689409
00
InteGrade engine value 140mm(6") 830
85
3,000
50,000
2
1NO / 24 24
INTGR140ENG830
235996
00
InteGrade engine value 575mm(23") 830
85
3,000
50,000
1
1NO / 24 24
INTGR575ENG830
236146
00
InteGrade engine vision 575mm(23") 840
85
4,100
50,000
1
1NO / 24 24
689546
00
InteGrade engine value 140mm(6") 840
85
4,160
50,000
2
1NO / 24 24
INTGR140ENG840
236016
00
InteGrade engine value 575mm(23") 840
85
4,160
50,000
1
1NO / 24 24
INTGR575ENG840
236184
00
InteGrade engine vision 575mm(23") 856
85
5,600
50,000
1
1NO / 24 24
689669
00
InteGrade engine eco 575mm(23") 865
85
6,500
50,000
1
1NO / 24 24
INTGR575ENG865
236221
00
InteGrade engine eco 140mm(6") 865
85
6,500
50,000
2
1NO / 24 24
INTGR140ENG865
236207
00
