Description
Modicon TSX Micro/Premium PLCs have a slot in the processor for a PCMCIA
communication card
(1)
which can be fitted with a
TSX FPP20
Fipio bus connection
card. This card can also be inserted into the
TSX SCY 21601
communication module
slot on Modicon Premium PLCs.
Description
,
same as that of the
TSX FFP10
Fipio bus card, see page 5/104.
References
Description
Number
per PLC
Use on
Reference
Weight
kg
Fipway card
(1)
1
with
TSX 37 20
TSX 57 10/20
3
with TSX 57 30
4
with TSX 57
40/50/60
TSX Micro and Premium
processor
TSX SCY 21601 module
TSX FPP20
0.110
Communication
module
2-
channels
See page 5/129 For Premium PLC
- 1
isolated 2-wire RS 485
integrated channel
(
Half-duplex)
- 1
slot for type lll PCMCIA
card
TSX SCY 21601
0.360
Set of X-Way
drivers for PC
compatible
Includes all X-Way drivers on one CD-ROM See page 6/43
–
Fipway network connection cables
(2)
Description
Use
From
To
Length Reference
Weight
kg
Corsets for
PCMCIA card
Card
TSX FPP20
(
miniature
connector)
TSX FPACC3/4
box (9-way SUB-D
connector)
1
m
TSX FP CG 010
0.210
3
m
TSX FP CG 030
0.310
(1)
TSX P57 4634M
/
5634
M
/
6634
M
Unity processors with integrated Ethernet port do not
support the
TSX FPP20
Fipway card in their PCMCIA slot.
(2)
For other accessories and connecting cables, see pages 5/112 and 5/113.
Description,
references
TSX SCY 21601
TSX FP CG010/030
Modicon Premium automation
platform
Fipway network
TSX FPP20
