Fipio bus/Fipway network wiring system
(
continued)
Cables
1
TSX FP CA
p
00
:
trunk cable, shielded twisted pair 150
(
Ø 8 mm) for normal
environments and inside buildings.
2
TSX FP CR
p
00
:
trunk cable, shielded twisted pair 150
(
Ø 9.5 mm) for harsh
environments or use outside buildings.
TSX FPCP
p
00
:
trunk cable, shielded twisted pair 150
(
Ø 9.5 mm) and 1 x 1.5 mm
2
pair for remote power supply for harsh environments or use outside buildings.
3
TSX FP CC
p
00
:
tap link cable, double shielded twisted pair 150
(
Ø 8 mm) for
normal environments and inside buildings.
4
TSX FP CG0
p
0
:
tap link cordset for
TSX FPP10/20/OZD200
PCMCIA card for
Modicon Micro/Premium/TSX Series 7 PLCs, and
TSX C USBFIP
USB/FIP
adaptor. Connection to the bus is via the 9-way SUB-D connector on the
TSX FPACC3
/
ACC4
box.
Connection boxes
6
TSX FPACC14
:
IP 20 polycarbonate junction box: provides tap link from the trunk
cable to connect 1 device via
TSX FP CC
p
00
tap link cable or several devices in a
daisy chain.
7
TSX FPACC3
:
IP 20 box for connecting 2
TSX FPP10/20/OZD200
PCMCIA
cards or a
TSX C USBFIP
USB/FIP adaptor on a 9-way SUB-D connector.
8
TSX FPACC4
:
IP 65 junction box. It also has a 9-way female SUB-D connector
for connecting a
TSX FPP10/20/OZD200
PCMCIA card or a
TSX C USBFIP
USB/FIP adaptor (in this case, the degree of protection of the box becomes IP 20).
TSX EF ACC99
:
IP 65 junction box for IP 67 I/O modules, please consult our website
www.schneider-electric.com.Connectors
9
TSX FPACC2
and
TSX FPACC12
: 9-
way female SUB-D connector for Fipway/
Fipio connection (TSX FPACC2 connector specifically for TSX 17 20 micro-PLC).
Used for daisy chain or tap link connection (90° high or low output, 45° high or low
output).
10
TBXBLP01
:
connector for IP20TBX I/Omodules
(
legacy range)
.
11
TSX LES65
:
terminal block for TSX/PMX model 40 PLCs
(
legacy range)
.
Used for
address coding.
12
TSX FPACC6
:
electrical repeater: used to increase the number of stations (64 max.)
and the length of the network by creating additional segments of up to 1000 m (a
maximum of 4 repeaters in cascade, giving a network length of 5000 m).
TSX EF C
ppp
:
dust and damp proof connectors for IP 67 I/O modules, please
consult our website
www.schneider-electric.com.
Other components
13
TSX FPACC8M
:
fibre optic/electrical repeater, used to interconnect electrical
segments via a fibre optic link (particularly suitable for crossing areas with a high
level of interference) or to connect a fibre optic device.
14
TSX FPACC7
:
line terminator, to be installed at both ends of a segment.
16
TSX C USBFIP:
USB/Fipio-Fipway adaptor, for connecting any device with a USB
port (Magelis XBT G
p
,
PC, Magelis
i
PC industrial PC). Max. rate 12 messages/s.
TSX EF ACC7
:
M23 IP67 line terminator, to be installed at one or both ends of a
segment, as required.
TSX FPACC9
:
network wiring test tool. This is used for testing the continuity of
segments, the connections of the various devices and the installation of line
terminators.
Fipio presentation:
page 5/100
Fipway presentation:
page 5/106
References:
pages 5/112 ...
Connections
(
continued)
Modicon Premium automation
platform
Fipio bus and Fipway network
