References (continued)
References (continued)
Fipio bus/Fipway network connecting cables (1)
Description Type Condition of use No. Length Reference Weight
kg
Trunk cables Ø 8 mm, 1 shielded
twisted pair 150 
In normal environment(2)
Inside building
1 100 m TSX FP CA100 5.680
200 m TSX FP CA200 10.920
500 m TSX FP CA500 30.000
Ø 9.5 mm, 1 shielded
twisted pair 150 
In harsh environment (3)
Outside building In
mobile installations (4)
2 100 m TSX FP CR100 7.680
200 m TSX FP CR200 14.920
500 m TSX FP CR500 40.000
Ø 9.5 mm, 1 shielded
twisted pair 150  and
1 x 1.5 mm2 pair for
24 V c remote supply
In harsh environment (3)
Outside building In
mobile installations (4)
– 100 m TSX FP CP100 7.680
500 m TSX FP CP500 30.000
Tap link cables Ø 8 mm, 2 shielded
twisted pairs 150 
In normal environment(2)
Inside building
3 100 m TSX FP CC100 5.680
200 m TSX FP CC200 10.920
500 m TSX FP CC500 30.000
Cordsets for
PCMCIATSX FPPpp cards
USB/FIP adaptor
With 1 miniature
connector and 1 x 9-way
SUB-D connector
In normal environment(2)
Inside building
4 1 m TSX FP CG010 0.210
3 m TSX FP CG030 0.310
(1) The characteristics and performance of the Fipio bus or Fipway network are dependent on the above TSX FP accessories
being used.
(2) Normal environment:
- Without any particular environmental restrictions
- Operating temperature between + 5°C and + 60°C
- Fixed installations
(3) Harsh environment:
- Resistance to hydrocarbons, industrial oils, detergents, solder splashes
- Humidity up to 100%
- Saline atmosphere
- Extreme temperature variations
- Operating temperature between - 10°C and + 70°C
- Mobile installations
(4) Mobile installations: cables as per VDE 472 part 603/H:
- For use on cable drag chain with minimum bend radius of 75 mm
- For use on gantry crane, subject to compliance with conditions for use such as acceleration, speed, length. Consult your
Customer Care Centre
- Not authorized for use on robots or multi-axis applications
Fipio presentation:
page 5/100
Fipway presentation:
page 5/106
Connections:
pages 5/110 ...
