250 / 413
5/116
References
Description Number per
PLC
Use
No.
Composition Reference
Weight
kg
Modbus Plus
PCMCIA card
1
with TSX Micro
37 21/22 1
with
Premium
Type III slot on:
-
TSX 37 21/22 PLC
-
TSX 57 1
p
/2
p
/3
p
/4
p
/5
p
/6
p
Premium processor
1
1
type III
PCMCIA card
TSX MBP 100
0.110
Description
Connection
No.
Reference
Weight
kg
Distributed I/O on Modbus
Plus network
Modicon STB network interface module
–
STB NMP 2212
0.145
Momentum communication module
2
170
PNT 110 20
0.110
Connection accessories
(1)
Description Use
No.
Mounting
Reference
(1)
Weight
kg
Modbus Plus
taps
IP 20 tee, requires the 043 509 383 wiring tool. Integrates the
line terminator
5
–
990
NAD 230 00
0.230
IP 20 tap for tap link connection
Connection on screw terminals,
supports 1 RJ45 connector on front panel
6
DIN rail
990
NAD 230 20
–
Plate
990
NAD 230 21
–
IP 65 tap for tap link connection, supports 1 RJ45 connector on
front panel
6
Plate
990
NAD 230 10
0.650
IP 20 tee with 2 RJ45 connectors for Modbus Plus cable and
1
x 9-way SUB-D connector for tap link devices
7
–
170
XTS 020 00
0.260
Line
terminators
Sold in lots of 2
For 990 NAD 230 20/21 tap (IP 20)
11
–
990
NAD 230 22
–
For 990 NAD 230 10 tap (IP 65)
11
–
990
NAD 230 11
–
For 170 XTS 020 00 tee (IP 20)
12
–
170
XTS 021 00
–
Used directly at the end of the trunk cable (with no tee or tap)
11
–
AS MBKT 185
–
Mounting kit
DIN rail mounting for 990 NAD 230 10 IP 65 tap
–
–
990
NAD 230 12
–
Protectors
Sold in lots of 4
Replacement protectors for RJ45 connector for access to the
terminal port on the 990 NAD 230 10 tap
–
–
990
NAD 230 23
–
Wiring tool
Mounting trunk and tap cables in 990 NAD 230 00 tap
–
–
043 509 383
–
(1)
For other Modbus Plus network accessories and connecting cables, consult your Customer Care Centre.
References
STB NMP 2212
TSX MBP 100
171
PNT 110 20
Modicon Premium automation
platform
Modbus Plus network
Presentation:
page 5/114
Connections:
page 5/115
