IP 20 connection accessories
Designation
Description
No.
(1)
Length Reference
Weight
kg
CANopen connector
for Altivar 71 drive
(2)
9-
way female SUB-D. Line end adaptor switch.
180
° cable outlet
–
–
VW3 CAN KCDF 180T
–
Adaptor
for
Altivar 61/71 drive
CANopen SUB-D to RJ45 adaptor
–
–
VW3 CAN A71
–
Preformed CANopen
cordsets
for Altivar
and Lexium 05 drives
1
RJ45 connector at each end
10
0.3
m
VW3 CAN CARR03
–
1
m
VW3 CAN CARR1
–
CANopen bus
adaptor
for Lexium 15
servo drive
Hardware interface for link conforming to the
CANopen standard + 1 connector for connection
of PC terminal
–
–
AM0 2CA 001V000
0.110
Y connector
CANopen/Modbus
–
–
TCS CTN011M11F
–
Designation
Description
No.
(1)
Sold in lots
of
Reference
Weight
kg
IP 20 line terminator
RJ45 connector
–
2
TCS CAR013M120
–
For screw terminal connector
–
2
TCS CAR01NM120
–
IP 67 connection accessories
Designation
Composition
Reference
Weight
kg
Connectors
Straight, M12, 5 screw terminals
Male
XZ CC12MDM50B
0.020
Female
XZ CC12FDM50B
0.020
Elbowed, M12, 5 screw terminals
Male
XZ CC12MCM50B
0.020
Female
XZ CC12FCM50B
0.020
(1)
For numbers, see page 5/89.
(2)
For ATV 71H
ppp
M3, ATV 71HD11M3X, HD15M3X, ATV 71H075N4... HD18N4 drives, this connector can be replaced by the
TSX CAN KCDF 180T
connector.
References
(
continued)
Presentation:
page 5/86
Description:
page 5/87
Software setup:
page 5/88
Wiring system:
page 5/89
Modicon Premium automation
platform
0
CANopen machine and installation bus
Wiring system
VW3 CAN A71
AM0 2CA 001V000
XZ CC12
p
DM50B
XZ CC12
p
CM50B
