Flat cables and line accessories
The special profile of these 2-core flat cables eliminates the risk of polarity reversal when connecting. Connections to
the cable are made by IDC (Insulation Displacement Connectors) connection accessories.
The material used for the cable sheath causes the holes made by the IDCs to reseal themselves as soon as the IDCs
are removed, thus maintaining the IP 67 protection of AS-Interface cabling accessories.
The ambient temperatures which AS-Interface flat cables can withstand are as follows, depending on the cable type:
b
Standard cable: 25…+ 85°C for operation, - 40…+ 85°C for storage
b
TPE cable (oil and vapour resistant): - 30…+ 105°C for operation with cable flexing, - 40…+ 105°C for non-flexing
operation or storage
Description
Sheath colour
No
.
Length Type of
cable
Reference
Weight
kg
Flat cables
2
x 1.5 mm
2
Ue
48
V
Yellow
(
for AS-Interface)
1
20
m Standard
XZ CB10201
1.400
TPE
XZ CB10201H
1.400
50
m Standard
XZ CB10501
3.500
TPE
XZ CB10501H
3.500
100
m Standard
XZ CB11001
7.000
TPE
XZ CB11001H
7.000
Black
(
for separate 24 V
c
power supply)
2
20
m Standard
XZ CB10202
1.400
TPE
XZ CB10202H
1.400
50
m Standard
XZ CB10502
3.500
TPE
XZ CB10502H
3.500
100
m Standard
XZ CB11002
7.000
TPE
XZ CB11002H
7.000
Description
Use
No
.
Length
Order in
multiples of
Unit reference Weight
kg
Line extension
Extends the length of a segment
from 100 to 200 m
3
–
–
TCS AAR011M
0.047
Repeater
Extends an AS-Interface line by
100
m
4
–
–
ASI RPT01
0.190
Heat shrinkable
cable end
To maintain IP67 degree of
protection at the end of the
AS-Interface cable
–
–
10
ASI 67FACC2
0.002
Accessories for connection to AS-Interface flat cables
Degree of protection: IP67, connection to flat cables by means of IDCs. Ue
40
V, Ie
2
A.
Ambient temperature: - 25°C…+ 70°C for operation, - 40…+ 85°C for storage
Tap-offs for connection of AS-Interface components
Description
Connection to AS-Interface
component
No
.
Cable
length
Fixing
Reference
Weight
kg
Tap-offs for
connection to a flat
cable
for
AS-Interface (yellow)
By 5-way female straight M12
remote connector
Cable 2 x 0.34 mm
2
–
1
m Screw
TCS ATN011F1
0.090
2
m Screw
TCS ATN011F2
0.130
By stripped wires for terminal block
Cable 2 x 0.34 mm
2
–
2
m Screw
TCS ATN01N2
0.215
Tap-offs for
connection to two
flat cables:
- 1
for AS-Interface
(
yellow)
- 1
for separate
power supply (black)
By 5-way female straight M12
remote connector
Cable 4 x 0.34 mm
2
5
1
m Screw
TCS ATV011F1
0.140
2
m Screw
TCS ATV011F2
0.180
By stripped wires for terminal block
Cable 4 x 0.34 mm
2
6
2
m Screw
TCS ATV01N2
0.265
T connectors
Description
Connection to the AS-Interface
component
No
.
Cable
length
Fixing
Reference
Weight
kg
T connectors for
connection to a flat
cable
for
AS-Interface (yellow)
By 5-way female M12 connector
7
–
Screw
TCS ATN011F
0.026
Tap-off
(
or extension)
for flat cables:
2
flat cables (yellow)
–
–
–
Screw
TCS ATN02V
0.019
XZ CB1
pp
0
p
TCS AAR011M
ASI RPT01
ASI 67FACC2
522173
TCS ATN011F
p
TCS ATV011F
p
TCS ATN011F
TCS ATN02V
Presentation:
page 5/92
Software setup:
page 5/93
Cabling system:
page 5/96
References
Modicon Premium automation
platform
AS-Interface cabling system
