5/90
Standard tap junctions and connectors
Designation
Description
No.
(1)
Length Reference
Weight
kg
IP 20 CANopen tap
junction
4
SUB-D ports. Screw terminals for connecting
the trunk cables
Line end adaptor
1
–
TSX CAN TDM4
0.196
IP 20 connectors
CANopen 9-way
female SUB-D.
Line end adaptor
switch
Elbowed (90°)
2
–
TSX CAN KCDF 90T
0.046
Straight
(2)
–
–
TSX CAN KCDF 180T
0.049
Elbowed (90°) with 9-way SUB-D for connecting
a PC or diagnostic tool
4
–
TSX CAN KCDF 90TP
0.051
IP 67 M12 connectors
Male
–
–
FTX CN 12M5
0.050
Female
–
–
FTX CN 12F5
0.050
IP 20 CANopen tap
junction
for Altivar and
Lexium 05
2
RJ45 ports
9
–
VW3 CAN TAP2
–
IP 20 standard cables and preassembled cordsets
Designation
Description
No.
(1)
Length Unit
reference
Weight
kg
CANopen cables
(
AWG 24)
Standard,
e
marking: low smoke. Zero halogen.
Flame-retardant (IEC 60332-1)
5
50
m
TSX CAN CA50
4.930
100
m
TSX CAN CA100
8.800
300
m
TSX CAN CA300
24.560
Standard, UL certification,
e
marking:
flame-retardant (IEC 60332-2)
5
50
m
TSX CAN CB50
3.580
100
m
TSX CAN CB100
7.840
300
m
TSX CAN CB300
21.870
For harsh environments
(3)
or mobile
installations,
e
marking: low smoke.
Zero halogen. Flame-retardant (IEC 60332-1).
Oil resistant
5
50
m
TSX CAN CD50
3.510
100
m
TSX CAN CD100
7.770
300
m
TSX CAN CD300
21.700
CANopen
preassembled
cordsets
One 9-way female
SUB-D connector at
each end
(
AWG 24)
Standard,
e
marking: low smoke. Zero halogen.
Flame-retardant (IEC 60332-1)
6
a
0.3
m
TSX CAN CADD03
0.091
1
m
TSX CAN CADD1
0.143
3
m
TSX CAN CADD3
0.295
5
m
TSX CAN CADD5
0.440
Standard, UL certification,
e
marking:
flame-retardant (IEC 60332-2)
6
a
0.3
m
TSX CAN CBDD03
0.086
1
m
TSX CAN CBDD1
0.131
3
m
TSX CAN CBDD3
0.268
5
m
TSX CAN CBDD5
0.400
CANopen
preassembled
cordsets
One 9-way SUB-D connector
1
RJ45 connector
(
AWG 24)
6
b
0.5
m
TCS CCN 4F3M05T
–
1
m
TCS CCN 4F3M1T
–
VW3 M38 05 R010
(4)
–
3
m
TCS CCN 4F3M3T
–
Two 9-way SUB-D connectors, one male and
one female
–
0.5
m
TLA CD CBA 005
–
1.5
m
TLA CD CBA 015
–
3
m
TLA CD CBA 030
–
5
m
TLA CD CBA 050
–
IP 67 standard preassembled cordsets
Designation
Description
No.
(1)
Length Unit
reference
Weight
kg
CANopen
preassembled
cordsets
Preassembled cordsets with two 5-way A-coded
elbowed M12 connectors (one male connector
and one female connector)
–
0.3
m
TCS CCN 2M2F03
0.090
1
m
TCS CCN 2M2F1
0.127
2
m
TCS CCN 2M2F2
0.179
5
m
TCS CCN 2M2F5
0.337
10
m
TCS CCN 2M2F10
0.600
15
m
TCS CCN 2M2F15
0.863
(1)
For numbers, see page 5/89.
(2)
The
VW3 CAN KCDF 180T
connector can also be used for connection to a Controller Inside programmable card.
(3)
Standard environment
:
-
Without any particular environmental stresses
-
Operating temperature between + 5°C and + 60°C
-
Fixed installation
Harsh environment:
-
Resistance to hydrocarbons, industrial oils, detergents, solder splashes
-
Humidity up to 100%
-
Saline atmosphere
-
Significant temperature variations
-
Operating temperature between - 10°C and + 70°C
-
Mobile installation
(4)
Cordset with line termination.
References
Presentation:
page 5/86
Description:
page 5/87
Software setup:
page 5/88
Wiring system:
page 5/89
TSX CAN KCDF 90T
TSX CAN KCDF 180T
TSX CAN KCDF 90TP
TSX CAN TDM4
VW3 CAN TAP2
