Wi-Fi antennas
(
continued)
Description
Frequency range
MHz
Gain
Degree
of protection
Reference
Weight
kg
2.4
GHz directional
antenna
2300 - 2500
14
dBi
IP 23
TCS WAB 2D
0.110
2.4
GHz dual slant antenna
2400 - 2485
8
dBi
IP 65
TCS WAB 2S
0.110
2.4
GHz Leaky cable, 50 m
2000 - 2900
0.15
dB
at 2.4 GHz
IP 65
TCS WAB C5
12.000
2.4
GHz Leaky cable, 100 m
2000 - 2900
0.15
dB
at 2.4 GHz
IP 65
TCS WAB C10
24.000
Cables
Description
Type
Length
m
Reference
Weight
kg
Adaptor cable
1
RP-SMAmale connector
1
N female connector
0.520
TCS WAAC
0.340
Adaptor cable
N-plug to N-jack, 2 m
1
N female connector
1
N male connector
2.000
TCS WABAC2
0.340
Adaptor cable
N-plug to N-jack, 15 m
1
N female connector
1
N male connector
15.000
TCS WABAC15
0.340
Accessories
Description
Degree
of protection
Type
Cable length
m
Reference
Weight
kg
Overvoltage protector for
antennas
–
N female,
N male
–
TCS WABP
0.080
Overvoltage protector for
LAN/PoE
IP 68
N female,
N male
–
TCS WABP68
0.080
Memory card modules
(1)
IP 40
Mini-DIN
connector
0.315
TCS WAMC67
0.035
IP 67
M12
connector
0.500
TCS WAMCD
0.025
Adaptor kit for pole
mounting
–
–
–
TCS WABMK
–
(1)
Auto-configuration adaptors which are used to save 2 different versions of the configuration and operating program data for
the Wi-Fi access point to which it is connected. They enable managed Wi-Fi access points to be easily commissioned and
quickly replaced.
TCS WAB 2D
TCS WAB C5
TCS WAAC
TCS WABP
TCS WAMCD
TCS WABAC2
TCS WABMK
Wi-Fi Access Points and Clients selection guide:
Pages 5/74 ...
Wi-Fi antenna selection guide:
Pages 5/78 ...
