214 / 413
5/80
Device type
5
GHz antennas
Description
5
GHz omnidirectional antenna
5
GHz dual slant antenna
Frequency range
5150 - 5875
MHz
5150 - 5925
MHz
Antenna gain
5
dBi
9
dBi
VSWR
(1)
1.5
2
Polarization
Linear, vertical
2
x linear, ± 45° slant
Horizontal HPBW
(2)
360
°
70
°
Vertical HPBW
(2)
25
°
60
°
Max. power
6
W
10
W (cw) at 25°C
Impedance
50
Ω
Connector
N female
2
x N female
Operating temperature
-45
°C to +70 °C
-40
°C to +80°C
Storage temperature
-45
°C to +70 °C
-40
°C to +80°C
Radome colour
Grey-white
RAL 7044 (Silk grey)
Radome material
Polypropylene
ASA, LEXAN EXL 9330
Weight
0.300
kg
0.110
kg
Dimensions
16
x 160 mm
101
x 80 x 35 mm
Wind load
–
15
N at 160 km/h
Degree of protection
IP 65
Shipping package contents
Cordset/cable
1
m cordset with N male connectors at
both ends
2
x 1 m cordsets with N male connectors at
both ends
Adaptor cable
Adaptor cable, R-SMAmale connector to
N female connector
2
x adaptor cables, R-SMAmale connector to
N female connector
Mounting kit
Yes
Access point/client compatibility
TCSG
pp pppp
TCSG
pp pppp
TCSN
pp pppp
References
TCS WAB 5O
TCS WAB 5S
Pages
5/84
(1)
VSWR: Voltage Standing Wave Ratio
(2)
HPBW: Half Power BeamWidth
Selection guide
(
continued)
Wi-Fi network
Wi-Fi antennas
