216 / 413
5/82
Device type
2.4
GHz antennas
Description
2.4
GHz omni directional
antenna
2.4
GHz directional
antenna
2.4
GHz dual slant
antenna
Frequency range
2400 - 2500
MHz
2300 - 2500
MHz
2400 - 2485
MHz
Antenna gain
6.0
dBi
14
dBi
8
dBi
VSWR
(1)
< 1.8
1.5
Polarization
Linear, vertical
Vertical
Dual linear,
± 45° slant
Horizontal HPBW
(2)
360
°
35
°
75
°
Vertical HPBW
(2)
–
30
°
70
°
Max. power
25
W
75
W (CW) at 25 °C
10
W (CW) at 25 °C
Impedance
50
Ω
Connector
N female
2
x N female
Operating temperature
-40
°C to +80°C
Storage temperature
-40
°C to +80°C
Radome colour
Grey-white
RAL 7044 (Silk grey)
Radome material
Fibreglass
LEXAN EXL 9330
Weight
0.340
kg
0.110
kg
Dimensions
Ø 22 mm x 250 mm
101
x 80 x 35 mm
Wind load
–
15
N at 160 km/h
Degree of protection
IP 65
IP 23
IP 65
Shipping package contents
Cordset/cable
1
m cordset with N male connectors at both ends
2
x 1 m cordsets with N male
connectors at both ends
Adaptor cable
Adaptor cable, R-SMAmale connector to N female connector 2 x adaptor cables, R-SMA
male to N female
Mounting kit
Yes
Access point/client compatibility
TCSG
pp pppp
TCSG
pp pppp
TCSG
pp pppp
TCSN
pp pppp
References
TCS WAB 2O TCS WAB 2D
TCS WAB 2S
Pages
5/84
5/85
(1)
VSWR: Voltage Standing Wave Ratio
(2)
HPBW: Half Power BeamWidth
Selection guide
(
continued)
Wi-Fi network
Wi-Fi antennas
2
1
3
4
5
6
7
8
9
10
