Distribution
Designed to resist ageing and creep, the busbar
supports, made of a heat-setting, insulating material,
offer a particularly high level of performance, notably
their withstand to high temperatures.
Their remarkable mechanical withstand means fewer
are required, thus freeing maximum space along the
busbars for the connection of devices.
PD390413
Multi-function busbar supports
The same support is used for all busbars up to 1600 A and can also be used as the
bottom support.
As a result, ordering is easy and stocking costs are reduced.
PD390393
Electrical connections without drilling
Tested in special test stations, copper connections are used to interconnect two sets
of busbars.
Connections are fast with 10 mm thick horizontal busbars.
Drilling is not required; the connections are made by clamping the busbars.
PD390415
An aluminium bar with a high-quality copper contact surface
A copper powder is thermally projected at high speed along the entire length of the
bar. It forms a rough, exceptionally hard surface. The quality of the electrical
connection is enhanced by the many contact points. The result is convincing and
even better than a traditional copper/copper connection.
Modern busbars
Linergy busbars are produced in a number of different shapes offering both a high
level of performance and good appearance. The anodisation process protects
against ageing and provides an attractive finish.. The copper-coloured bands along
the entire length reflect the modern design and high technology of these busbars.
Presentation of Linergy busbars
Main distribution
