Distribution
Presentation of busbars
Linergy
busbars are installed in a busbar zone to the left or right of the device zone.
The busbars are secured to the framework by supports that maintain the distances
between busbars. All connection points are directly access ble from the front of the
switchboard.
The bars are channelled and the devices, installed on either side, can be connected
at any height, without drilling.
PD391305
PD390402
PD390403
Sliding bolts enable connections at any height,
without drilling.
All connection points are directly accessible
from the front of the switchboard.
PD391306
PD390405
Prefabricated connections supply the devices
mounted to the left or right of the busbars.
The bottom support maintains the bars in
position.
Presentation of Linergy busbars
Main distribution
