Distribution
Horizontal-busbar connections
These connections are used to connect horizontal busbars, 5 or 10 mm thick, to
vertical rear Linergy busbars.
DD381244
Designation
Cat. no.
Connection to horizontal busbars, 5 mm thick
04635
(1)
(2)
Connection to horizontal busbars, 10 mm thick
width of horizontal bars
y
80 mm
04636
(1)
(2)
width of horizontal bars > 80 mm
04636
(2)
+ 04642
(1)
(1)
A part of the connection must be made.
(2)
Catalogue numbers 04635 and 04636 include 1 connection only. Order 1 connection per
phase.
Connection to horizontal busbars, 5 mm thick.
DD381245
Connection to horizontal busbars, 10 mm thick.
Rear Linergy busbars
up to 1600 A
