TECHNICAL INFORMATION
Technical information
266 |
PowerPoles and PowerPosts
A
C
B
D
E
F
E
G
K
I
J
C
L
DOUBLE
SIDED
POWERPOLE
A
C
B
D
F
E
G
K
I
J
C
L
SINGLE
SIDED
POWERPOLE
Double sided PowerPole
Code
Description
Quantity
PP36001 250mm adj. slide incl
1 pack
PP36002 1150mm adj. slide incl
1 pack
A PPFB2
Fixing Bracket
1
B PHAS1/2 *Adjusting Slide
1
C PPSN1
Sliding Nut
3
D PPTC1
Top Cover (white only)
1
E PL1
Lid 3600mm
2
F PPMB1
Pole 3600mm
1
G ESSB1
Single Gang Box
6
I
PPBF3
Base Foot (Metal)
1 pair
J PPBF1
Base Foot (white only)
1
K ES1
Spacing Cover
5
L PPBT1
16mm Bonding Terminal Ass.
1
PPF1
Fixing Kit
1
*The Sterling PowerPole is suitable for both solid
and suspended ceilings up to 3.6 metres high. An
alternative adjusting slide which can be extended to
one metre is available for additional heights within
the ceiling void.
1400mm Extension Pole body kits available to
increase Pole height to 5.0m.
Full installation instructions are
included within each pack.
Single sided PowerPole
Code
Description
Quantity
PPS36001 250mm adj. slide
1 pack
PPS36002 1150mm adj. slide
1 pack
A PPFB2
Fixing Bracket
1
B PHAS1/2 *Adjusting Slide
1
C PPSN1
Sliding Nut
3
D PPTC2
Top Cover (white only)
1
E PL1
Lid 3600mm
1
F PPSS1
Single Sided Pole 3600mm
1
G ESSB1
Single Gang Box
6
I
PPBF3
Base Foot (Metal)
1
J PPBF4
Base Foot (white only)
1
K ES1
Spacing Cover
5
L PPBT1
16mm Bonding Terminal Ass.
1
PPF1
Fixing Kit
1
*The Sterling PowerPole is suitable for both solid
and suspended ceilings up to 3.6 metres high. An
alternative adjusting slide which can be extended to
one metre is available for additional heights within
the ceiling void.
1400mm Extension Pole body kits available to
increase Pole height to 5.0m.
Full installation instructions are
included within each pack.
B C B
A
11
11
97
102
28
46
28 39
16
98
C B
B
28
63
102
28
28 39
Double sided PowerPole
A = 2017 sq mm total area 45% space
factor = 907 sq mm.
Without Accessory Box
A = 4284 sq mm total area 45% space
factor = 1927 sq mm.
B = 1148 sq mm total area 45% space
factor = 516 sq mm.
C = 1547 sq mm total area 45% space
factor = 696 sq mm.
Single sided PowerPole
B = 1115 sq mm total area 45% space
factor = 502 sq mm.
C = 1119 sq mm total area 45% space
factor = 504 sq mm.
Dimensions and cable capacities
