20
Product
Trunking size
110
130
170
170A
Cat. Nos.
Weight
Cat. Nos.
Weight
Cat. Nos.
Weight
Cat. Nos.
Weight
Body 3 m
MP351243 5·56 MP351245 6·27 MP351236
1
7·68 MP351247 7·68
Lid 1·5 m
MP351230 0·98 MP351230 0·98 MP351230 0·98 MP351230 0·98
Accessory spacer lid 100 mm
MP351220 0·07 MP351220 0·07 MP351220 0·07 MP351220 0·07
Coupler
2
MP351523 0·08 MP351525 0·09 MP351526 0·05 MP351527 0·11
Universal internal/external bend lid
MP351173 0·23 MP351175 0·24 MP351176 0·27 MP351177 0·27
Internal bend cover straps
MP351203 0·37 MP351205 0·37 MP351206 0·38 MP351207 0·38
Internal bend body
MP351273 0·47 MP351275 0·52 MP351276 0·62 MP351277 0·62
External bend body
MP351303 0·53 MP351305 0·59 MP351306 0·71 MP351307 0·71
External bend lid
MP351240 0·26 MP351240 0·26 MP351240 0·26 MP351240 0·26
Flat bend body
MP351333 0·44 MP351335 0·65 MP351336 1·09
–
–
Flat bend lid
MP351260 0·21 MP351260 0·21 MP351260 0·21 MP351260 0·21
Flat bend body rising
–
–
–
–
–
–
MP351337 1·08
Flat bend body descending
–
–
–
–
–
–
MP351367 1·10
Tee body
MP351393 0·62 MP351395 0·74 MP351396 0·99
–
–
Tee body rising
–
–
–
–
–
–
MP351397 0·96
Tee body descending
–
–
–
–
–
–
MP351427 1·01
Tee cover strap
MP351563 0·15 MP351565 0·20 MP351566 0·30
MP351567
3
MP351597
4
0·29
End cap
MP351043 0·08 MP351045 0·08 MP351046 0·10 MP351046 0·10
Cover strap
MP351103 0·05 MP351105 0·06 MP351106 0·07 MP351107 0·07
Tolerance cover strap
MP351073 0·09 MP351075 0·10 MP351076 0·11 MP351077 0·11
Wall flange plate
MP351483 0·05 MP351485 0·05 MP351486 0·06 MP351486 0·06
Wall flange closing plate
MP351513 0·03 MP351515 0·03 MP351516 0·04 MP351516 0·04
Support flange
MP351453 0·13 MP351455 0·14 MP351456 0·15 MP351456 0·15
Riser trunking body
2
– 2 m
MP351409 5·60 MP351409 5·60 MP351409 5·60 MP351409 5·60
Riser trunking lid – 1 m
MP351439 1·47 MP351439 1·47 MP351439 1·47 MP351439 1·47
Earthing wire
MP351499 0·01 MP351499 0·01 MP351499 0·01 MP351499 0·01
Universal snapper clip
2
MP351319 0·06 MP351319 0·06 MP351319 0·06 MP351319 0·06
Divider
2
– 1 m
MP351189 0·36 MP351189 0·36 MP351189 0·36 MP351189 0·36
Base divider
2
– 2 m
–
–
MP351279 0·47 MP351289 0·66 MP351289 0·66
Base divider fixing bracket
2
–
–
MP351299 0·02 MP351309 0·02 MP351309 0·02
Internal lid support
2
MP351469 0·03 MP351469 0·03 MP351469 0·03 MP351469 0·03
Internal bend lid
MP351250 0·12 MP351250 0·12 MP351250 0·12 MP351250 0·12
End support bracket
2
MP351449 0·03 MP351449 0·03 MP351449 0·03 MP351449 0·03
Tee support bracket
2
MP351459 0·03 MP351459 0·03 MP351459 0·03 MP351459 0·03
Acoustic insulation block
MP351389 0·05 MP351389 0·05 MP351399 0·05 MP351399 0·05
Cutting support block
MP351533 1·51 MP351535 1·64 MP351536 1·89 MP351536 1·89
Touch-up paint
MP351029 0·04 MP351029 0·04 MP351029 0·04 MP351029 0·04
1 gang back box
MP820329 0·85 MP820329 0·85 MP820329 0·85 MP820329 0·85
2 gang back box
MP820339 0·15 MP820339 0·15 MP820339 0·15 MP820339 0·15
n
Weights
steel perimeter trunking
technical information
1 : All trunking body lengths supplied in packs of 2 x 3 m lengths except Cat. No. MP351236 which is supplied singly 2 : Internal components supplied unpainted
3 : Rising to 170 mm wide trunking 4 : Rising to 130 mm wide trunking
