28
Pack
Cat. Nos.
150 mm plastic grommets
Hole size 152 mm
Carpet recess optional on power versions
Secured by quarter-turn fasteners
1
SG6
Access grommet
Allows power, data and flexible conduit
up to 32 mm to pass safely through
raised access floor
Maximum number of conduit entries :
9 x 20 mm Ø
5 x 25 mm Ø
3 x 32 mm Ø
1
PG6
13 A power grommet
Supplied complete with
13 A unswitched socket
1
PG6RCD
RCD power grommet
Supplied complete with 13 A RCD socket
1
PG6PD
13 A power/data grommet
Supplied complete with 13 A socket and
1 x 37 x 22 mm cut-out
1
PG6D
Data grommet
Supplied complete with data plate
2 x 37 x 22 mm cut-out
Pack
Cat. Nos.
125 mm aluminium grommets
Hole size 127 mm
Body – cast aluminium
Lid – injection moulded plastic Nylon 66 with
neoprene cable gasket
Secured by quarter-turn fasteners
Floor depth 25 to 55 mm
Access grommet depth 60 mm
(95 mm when back box included)
1
089307
Access grommet
Allows power, data and flexible
conduit up to 25 mm to pass safely
through raised access floor
1
AM1C
13 A power grommet
Supplied complete with 13 A
unswitched socket
250 mm grommet
Hole size 250 mm
Manufactured from polycarbonate/ABS
Colour : grey to BS 4800 18B25
Secured by quarter-turn fasteners
Floor depth 15 to 35 mm
7 mm lid recess
Depth 55 mm
1
LSG2
Access grommet
Allows power, data and flexible
conduit up to 32 mm to pass safely
through raised access floor
089307
AM1C
cavity floor
grommets
All power grommets are available pre-wired
Contact us on +44 (0) 870 608 9020
Dimensions and technical information
p. 31
PG6
LSG2
SG6
PG6RCD
