24
No. of compartments
Floor box base
Cavity loor box base – 75 mm deep
Depth
Cavity loor box base – 85 mm deep
Cavity loor box base – 110 mm deep
Socket outlet plates
13 A twin switched socket plate
13 A twin unswitched socket plate
13 A standard
13 A twin switched clean earth socket plate
13 A triple unswitched socket plate
13 A triple unswitched clean earth socket plate
13 A non-standard
13 A twin NS switched socket plate
13 A twin NS switched clean earth socket plate
RCD 30 mA passive
2 gang RCD socket plate
2 gang RCD socket plate – clean earth
37 x 22 mm – 2 cut-out plate
37 x 22 mm – 4 cut-out plate
Data
37 x 22 mm – 4 cut-out wave plate
37 x 22 mm – 6 cut-out plate
47·5 x 23·5 mm – 4 cut-out plate
2 x standard single outlet 60·3 mm
Standard 2 gang outlet plate 120·6 mm
51 x 51 mm – 1 cut-out plate
General
51 x 51 mm – 2 cut-out plate
Blank plate
58 x 53·5 mm – 1 cut-out plate to accept Arteor mounting frame
1
58 x 53·5 mm – 2 cut-out plate to accept 2 x Arteor mounting frames
1
Lids and trims
ABS with carpet trim – 6 mm recess
Combination with edge trim – 6 mm recess
Metal, powder coated with carpet trim – 8 mm recess
Metal, powder coated with edge trim – 8 mm recess
Stainless steel with carpet trim – 8 mm recess
Stainless steel with edge trim – 8 mm recess
Brass with carpet trim – 8 mm recess
Brass with edge trim – 8 mm recess
1 : For Arteor mounting frames, refer to the latest Wiring Devices catalogue
cavity floor service outlet boxes
selection chart
