Pack
Cat. Nos.
Support frames and surround plates for
Arteor socket modules
Support frames
Material : plastic
For 2 or 3 modules
10
MP351069 118 x 80 mm
For 4 or 6 modules
10
MP351109 191 x 80 mm
Surround plates – RAL 9010
Material : plastic
Use with 2/3 module support frame
Cat. No. MP351069
10
MP351049 2 modules
10
MP351059 3 modules
Use with 4/6 module support frame
Cat. No. MP351109
10
MP351089 4 modules
10
MP351099 6 modules
Arteor sockets (modular)
Shuttered for child safety
Use support frames and surround
plates above
Number of
modules
(22·5 x 45 mm)
Conform to BS 546 : 1950
10
5721 10
5 A single unswitched socket
2
Conform to BS 1363 – Part 2 : 1995
10
5721 11
1
13 A single unswitched socket
2
Conform to BS 1363 – Part 2 : 1995
5
5721 30
13 A single switched socket
3
Conform to BS 546 : 1950
5
5721 32
15 A single switched socket
3
5
5724 67
13 A single switched
3
non-standard socket
Pack
Cat. Nos.
Back boxes and contrast frames
Socket back boxes
Material : pre-galvanised steel
1
MP820329 1 gang back box
1
MP820339 2 gang back box
Contrast frames
Aid Part M compliance when using
Synergy white wiring accessories
(see below)
10
8218 46
1 gang contrast frame
10
8218 47
2 gang contrast frame
Synergy sockets (monobloc)
Front plates : white thermoset
Terminal screws backed off and ready for cabling
Supplied with optional faceplate screw caps
Synergy white wiring accessories
Conform to BS 1363 - Part 2 : 1995
10
7300 60
13 A single switched socket
Conform to BS 1363 - Part 2 : 1995
5
7300 70
13 A twin switched socket
Conform to BS 7288 : 1990 and
BS 1363 - Part 2 : 1995
1
7300 98
13 A twin RCD 30 mA passive socket
Synergy brushed stainless steel
wiring accessories
Front plates : brushed stainless steel
with clear epoxy satin lacquer coating
Conform to BS 1363 - Part 2 : 1995
1
7330 60
13 A single switched socket brushed
stainless steel
Conform to BS 1363 - Part 2 : 1995
1
7330 70
13 A twin switched socket brushed
stainless steel
Conform to BS 7288 : 1990 and
BS 1363 - Part 2 : 1995
1
7330 98
13 A twin RCD 30 mA passive socket
brushed stainless steel
MEIGaN socket outlets
For use in healthcare establishments
Engraved in white lettering
'MEDICAL EQUIPMENT ONLY'
Conform to BS 1363 - Part 2 : 1995
1
8204 50
13 A single switched socket (MEIGaN)
blue stainless steel
Conform to BS 1363 - Part 2 : 1995
1
8204 51
13 A twin switched socket (MEIGaN)
blue stainless steel
wiring accessories
Red
White
MEDICAL
EQUIPMENTONLY
MEDICALEQUIPMENTONLY
White
For complete range of wiring accessories
see Legrand's Wiring Devices catalogue
Blue/White
Brushed
stainless steel
1 : when using two or more Arteor unswitched 13 A sockets (Cat. No. 5721 11) next to each other,
it is necessary to separate the sockets with a 1 module spacer (Cat. No. 5723 41)
