Pack Cat. Nos. Fittings (continued)
1 MP351045 End cap B
Cover strap C
10 MP351105 Width – 25 mm
Tolerance cover strap D
8 MP351075 Width – 40 mm
1 MP351485 Wall flange plate E
1 MP351515 Wall flange closing plate F
1 MP351455 Support flange
Riser trunking body 170 x 38 mm1 G
1 MP351409 Pre-galvanised
Length – 2 m
Riser trunking lid H
1 MP351439 Friction fit
Length – 1 m
Earthing wire
1 MP351499 Length – 300 mm
steel perimeter trunking system – 130 x 63 mm
for dado applications (continued)
MP351045 MP351335 MP351395 MP351105 MP351075
Selection charts p. 6-7
Dimensions and technical information p. 17-21
Installation material p. 21
Pack Cat. Nos. Regular power and data separation
Universal snapper clip 1 I
20 MP351319 Multifunction clip for fitting of divider,
separation of cables (50 mm) and
additional support of lid
Divider1 K
10 MP351189 Requires universal snapper clip
Cat. No. MP351319
Length – 1m
Additional partition for the base
Base divider1
Fixing bracket required (below)
Length – 2 m
10 MP351279 Height – 22 mm, for type 130
Base divider fixing bracket 1
10 MP351299 Height – 21 mm, for type 130
1 per metre required
Additional products IP 40 / IK 07
Internal lid support1
1 MP351469 Fits inside lid joints to achieve IP 40
Internal bend lid
1 MP351250 To achieve IP 40 on internal bends
End support bracket1
5 MP351449 Provides additional lid support
at end of run
Use to achieve IK 07
Tee support bracket1
5 MP351459 Fits inside lid joints to achieve IP 40
at tee junction
Accessories
Acoustic insulation block J
For use when trunking passes
through walls to reduce noise travel
1 MP351389 Self extinguishing plastic
Acoustic tested according to
NEN 5077/ISO 140/4
Cutting support block
1 MP351535 Holds trunking in position and
guides saw for a straight cut
Steel
Touch-up paint
1 MP351029 Contents – 10 ml
MP351245
1: Internal components supplied unpainted
