Legrand - Viking 3 Terminals

16 / 36

16
(1) Built-in end cap
Pack Cat. Nos. Connecting
Grey for standard circuit, blue for neutral conductor,
orange for circuit not broken by the master isolating
device
1 connection - 2 cables - 1 entry/1 outlet
Colour
Nominal
cross-
section
(mm²)
Capacity
Width
(mm)
Rigid cable
(mm2)
Flexible
cable
(mm2 )
Flexible
cable with
ferrule
(mm2)
60 0372 60 Grey
4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 2 . 5 5 60 0372 00 Blue
60 0372 20 Orange
50 0372 61(1) Grey
4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 4 6 50 0372 01(1) Blue
50 0372 21(1) Orange
50 0372 62(1) Grey 6 0 . 5 to 6 0 . 5 to 6 0 . 5 to 6 8
50 0372 02(1) Blue
40 0372 63(1) Grey 10 0 . 75 to 10 0 . 75 to 10 0 . 75 to 10 10
40 0372 03(1) Blue
10 0372 64(1) Grey 16 4 to 16 4 to 16 4 to 16 12
10 0372 04(1) Blue
1 connection - 3 cables - 1 entry/2 outlets
60 0372 40 Grey
4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 2 . 5 5 60 0372 41 Blue
60 0372 42 Orange
50 0372 43(1) Grey 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 4 6
50 0372 44(1) Blue
1 connection - 4 cables - 2 entries/2 outlets
60 0372 46 Grey 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 2 . 5 5
60 0372 47 Blue
50 0372 69(1) Grey 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 4 6
50 0372 09(1) Blue
2 connections - 4 cables - 2 levels
60 0372 67 Grey 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 2 . 5 5
60 0372 07 Blue
50 0372 68(1) Grey 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 4 6
50 0372 08(1) Blue
Pack Cat. Nos. For protection conductor
Metal base
Screwless fixing on rail
PEN from 10 mm2
1 connection - 2 cables - 1 entry/1 outlet
Colour
Nominal
cross-
section
(mm²)
Capacity
Width
(mm)
Rigid cable
(mm2 )
Flexible
cable
(mm2 )
Flexible
cable with
ferrule
(mm2 )
60 0372 70 Green/
yellow 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 2 . 5 5
50 0372 71 (1) Green/
yellow 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 4 6
25 0372 72 (1) Green/
yellow 6 0 . 5 to 6 0 . 5 to 6 0 . 5 to 6 8
20 0372 73 (1) Green/
yellow 10 0 . 75 to 10 0 . 75 to 10 0 . 75 to 10 10
15 0372 74 (1) Green/
yellow 16 4 to 16 4 to 16 4 to 16 12
1 connection - 3 cables - 1 entry/2 outlets
40 0372 10 Green/
yellow 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 2 . 5 5
30 0372 11 (1) Green/
yellow 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 4 6
1 connection - 4 cables - 2 entries/2 outlets
40 0372 12 Green/
yellow 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 2 . 5 5
30 0372 79 (1) Green/
yellow 4 0 . 5 to 6 0 . 5 to 4 0 . 5 to 4 6
Viking 3 terminal blocks with spring connection
Screwless connection system, stainless steel spring type
Used to make the electrical connection between 2 rigid copper cables, or flexible cables with or without ferrules
Direct tool-free insertion of a rigid cable or flexible cable with ferrule, up to 6 mm width
2 areas for bridging combs for alternating equipotential connection
For rails 2 depth 15 mm, 2 EN 60715 depth 7. 5 mm and 15 mm
0372 60 + 0372 00 + 0372 20 0372 63 0372 40 0372 21 0372 01
Automatic insertion of stripped
cable with ferrule cap or rigid
cable up to width of 6 mm
0372 72 0372 79
Red catalogue numbers: New products
NEW
0372 70
Automatic fixing on rail 4
