Legrand - Viking 3 Terminals

13 / 36

13
Red catalogue numbers: New products
SPRING CONNECTION
TERMINAL BLOCKS
Nominalcapacity
(mm
2)
Width (mm)Cat. Nos.(old range)Cat. Nos.
(newrange)
Standard
1 connection
2 cables
2 . 5 5 0396 01 0372 60
4 6 0396 04 0372 61
6 8 – 0372 62
10 10 – 0372 63
16 12 – 0372 64
3 cables
1 entry - 2 outlets
2 . 5 5 0396 02 0372 40
4 6 – 0372 43
4 cables
1 entry - 2 outlets 2 . 5 5 0396 03 0372 46
2 connections
2 levels 4 cables
1 . 5 5 0396 27 0372 67
4 6 0396 36 0372 68
For neutral
conductor
1 connection
2 cables
2 . 5 5 – 0372 00
4 6 – 0372 01
6 8 – 0372 02
10 10 – 0372 03
16 12 – 0372 04
3 cables
1 entry - 2 outlets
2 . 5 5 – 0372 41
4 6 – 0372 44
4 cables
1 entry - 2 outlets 2 . 5 5 – 0372 47
2 connections
2 levels 4 cables 4 6 – 0372 08
Disconnect 1 connection 2cables
Blade
type 4 6 – 0372 84
for
cartridge
5 x 20
4 6 – 0372 81
Diode carrier 1 connection 4 cables 2 . 5 5 – 0372 54
For
protection
conductor
1 connection
2 cables
2 . 5 5 0396 21 0372 70
4 6 0396 24 0372 71
6 8 0396 25 0372 72
10 10 – 0372 73
16 12 – 0372 74
3 cables
1 entry - 2 outlets
2 . 5 5 – 0372 10
4 6 0396 30 0372 11
4 cables
1 entry - 2 outlets 2 . 5 5 – 0372 12
2 connections
2 levels 4 cables 4 6 – 0372 79
END STOPS
Cat. Nos.
(old range)
Cat. Nos.
(new range)
12 width end stop, tri-rail 0394 00 0375 13
8 width end stop, rail 1 0394 02 –
8 width end stop, rail 2 0394 03 0375 11
10 width stop, bar support – 0375 12
old range: Viking 3 terminal blocks and accessories
and equivalences between old/new range (continued)
SPRING CONNECTION ACCESSORIES
Cat. Nos
(old
range)
Cat. Nos.
(new
range)
End cap
0396 31 037586
Std term. block - 2 cables -
width 5-6
0396 32 037587 Std term. block - 3 cables -
width 5
0396 77 – Std term. block - 3 cables -width 6
0396 33 037588
Std/diode term. block -
4 cables - width 5
0396 48 037589 Std term. block - 4 cables -
2 levels - width 5
0396 85 – Std term. block - 4 cables -2 levels - width 6
0396 43 037586
Protection cond. term.
block -
2 cables -width 5-6
Cat. Nos
(old
range)
Cat. Nos.
(new
range)
Separation/insulation divider
0396 49 – Block with 2 cables - width5-6
0396 50 – Block with 3 cables - width 5
Equipotential bridging
comb
0396 58 – Block - width 5 - 2 poles
0396 59 – Block - width 5 - 3 poles
0396 60 – Block - width 5 - 10 poles
0396 61 037505 Block - width 6 - 2 poles
0396 62 – Block - width 6 - 3 poles
0396 63 – Block - width 6 - 10 poles
SCREW CONNECTION ACCESSORIES
Cat.Nos.
(old range)
Cat.Nos.
(new range) End cap
0394 50 0375 50 Block with 1 connection - width 5-6
0394 51 0375 55 Block with 1 connection - width 8-10
0394 52 0375 51 Block with 1 connection - width 12-15
0394 82 – Block with 1 connection 1 entry/2 outlet - width 6
0394 55 0375 53 Block with 2 connections - width 5-6
0394 53 0375 54 Sensor/actuator block - 3 connections Cat. Nos. 0390 51/52
0394 73 – Block with 1 connection V.O. - UL 94 - width 5-6
0394 74 – Block with 1 connection V.O. - UL 94 - width 8-10
0393 49 – Disconnect terminal - 1 connection Cat. Nos. 0390 85/86
0393 48 – Disconnect terminal - 2 connections Cat. No. 0390 88
0393 09 – Neutral block - 1 connection - width 5-6
0393 11 – Neutral block - 1 connection - width 8-10
0393 13 – Neutral block - 1 connection - width 12-15
0393 15 0375 53 Neutral block - 2 connections - width 5-6
0393 46 – Block for circuit not broken - 1 connection Cat. No. 0393 39
0393 45 0375 55 Block for circuit not broken - 1 connection Cat. No. 0393 38
0393 84 0375 52 Block for cond. protection - 2 connections Cat. No. 0393 73
0393 87 – Block for cond. protection - 1 connection Cat. No. 0393 81
0393 88 – Block for cond. protection - 1 connection Cat. No. 0393 82
Separation/insulation divider
0394 66 0375 60 Block with 1 connection width 5-6-8-10 and disconnect. width 6
0394 69 0375 63 Blocks with 2 connections width 5-6
0394 67 0375 62 Blocks with 1 connection width 12-15 and disconnect. width 8
0394 53 0375 54 Blocks with 3 connections width 5
Equipotential bridging comb
0394 31 – Width 5 - 12 blocks
0394 20 0375 04 Width 6 - 12 blocks
0394 21 – Width 8 - 12 blocks
0394 40 0375 02 Width 5 - 2 blocks
0394 43 0375 05 Width 6 - 2 blocks
0394 41 – Width 5 - 3 blocks
0394 44 – Width 6 - 3 blocks
0394 22 0375 47 Sens./act. - width 5 - blue - 12 blocks
0394 23 0375 46 Sens./act. - width 5 - brown - 12 blocks
0394 26 – Sens./act. - width 5 - green - 12 blocks
Equipotential bridging bar
0394 10 0375 01 Insulated - width 5 - 12 blocks
0394 11 0375 04 Insulated - width 6 - 12 blocks
0394 12 – Insulated - width 8 - 12 blocks
0394 34 – Insulated - width 5 - 2 blocks
0394 37 0375 05 Insulated - width 6 - 2 blocks
0394 35 – Insulated - width 5 - 3 blocks
0394 38 0375 02 Insulated - width 6 - 3 blocks
0394 13 0375 40 Bare - width 10 - 12 blocks
0394 14 0375 42 Bare - width 12 - 12 blocks
0394 15 0375 44 Bare - width 15 - 12 blocks
0394 16 0375 40 Bare - width 10 - 12 blocks - low spacer
0394 17 0375 42 Bare - width 12 - 12 blocks - low spacer
0394 18 0375 44 Bare - width 15 - 12 blocks - low spacer
Protective screen
0394 92 0375 65 Single pole for block with 1 connection - width 5-6
0394 93 0375 66 Single pole for block with 1 connection - width 8-10
0394 94 0375 67 Single pole for block with 1 connection - width 12-15
0394 80 0375 68 Cut to length - width 5-6-8-10 (on Cat. No. 0394 66)
0394 81 0375 69 Cut to length - width 12-15 (on Cat. No. 0394 67)
Miscellaneous
0394 05 0375 35 Screening continuity bracket for
1 connection blocks - width 5-6-8-10
0394 95 –
Protection cap for separable combs/
bars - width 5-6
