(1) Rigid cable capacity: 2 . 5 mm² max with equipotential brigding comb
Viking 3
terminal blocks with screw connection (continued)
Used to make the electrical connection between 2 rigid or flexible copper cables
2 areas for bridging combs for alternating equipotential connection up to 8 width
For rails
2
depth 15 mm,
2
EN 60715 depth 7. 5 mm and 15 mm
0371 80
+ automotive-type fuse
0371 55
0371 82
+
0371 83
+
0371 85
0371 51
0371 52
0371 84
+
0371 86
0371 53
0371 92
0371 87
Technical characteristics (p. 20-21) Accessories (p. 18) End stops (p. 18) see p. 30 New Starfix crimping toolsRed catalogue numbers: New products
Pack
Cat. Nos.
Disconnect terminal blocks 1 connection
Disconnection by means of blade type lever, handle
lever or mini lever (with tool)
Open (to be equipped)
Can take a blade-type automotive fuse or a miniature
circuit breaker, or blade type levers
Cat. Nos. 0375 15/16/17/18
Colour
Nominal
cross-
section
(mm²)
Capacity
Width
(mm)
Rigid cable
(mm
2
)
Flexible
cable (mm
2
)
20
0371 80
Grey
2 . 5 0 . 25 to 2 . 5 0 . 25 to 2 . 5 6
For fuse cartridge 5 x 20 with handle lever
20
0371 81
Grey
2 . 5 0 . 25 to 2 . 5 0 . 25 to 2 . 5 6
For neutral circuit with blue handle lever
20
0371 82
Grey/blue 2 . 5 0 . 25 to 2 . 5 0 . 25 to 2 . 5 6
For standard circuit with handle lever
20
0371 83
Grey
2 . 5 0 . 25 to 2 . 5 0 . 25 to 2 . 5 6
For standard circuit with mini lever
20
0371 84
Grey
2 . 5 0 . 25 to 2 . 5 0 . 25 to 2 . 5 6
For circuit not broken with handle lever
Circuit not broken by the master isolating device
20
0371 85
Orange 2 . 5 0 . 25 to 2 . 5 0 . 25 to 2 . 5 6
For circuit not broken with mini lever
Circuit not broken by the master isolating device
20
0371 86
Orange 2 . 5 0 . 25 to 2 . 5 0 . 25 to 2 . 5 6
For cartridge 5 x 20 with screwed plug
20
0371 87
Grey
10 0 . 25 to 16 0 . 25 to 10 12
For cartridge 6·3 x 32 with screwed plug
20
0371 88
Grey
10 0 . 25 to 16 0 . 25 to 10 12
Pack
Cat. Nos.
Function blocks
1 connection - modular
Component connected with screws
Colour
Nominal
cross-section
(mm²)
Capacity
Width
(mm)
Rigid cable
(mm
2
)
Flexible
cable (mm
2
)
20
0371 53
Grey
2 . 5
0 . 25 to 4 0 . 25 to 2 . 5 5
1 connection - diode carrier
20
0371 54
Grey
2 . 5
0 . 25 to 4 0 . 25 to 2 . 5 5
2 connections on 2 levels - diode carrier
60
0371 55
Grey
4
0 . 25 to 6 0 . 25 to 4 6
2 connections on 2 levels - with LED
Voltage presence indicator (12/24V
=
/
A
)
60
0371 56
Grey
4
0 . 25 to 6 0 . 25 to 4 6
For sensors and actuators
For connecting sensors (Cat. No. 0371 51) or
actuators (Cat. No. 0371 52), and their shared power
supply unit using equipotential bridging comb
Cat. Nos. 0375 46/47 (wiring diagram p. 21)
3 connections on 3 levels - for sensor
Colour
Nominal
cross-section
(mm²)
Capacity
Width
(mm)
Rigid cable
(mm
2
)
Flexible
cable (mm
2
)
50
0371 51
(1)
Grey
2 . 5
0 . 25 to 4 0 . 25 to 2 . 5 5
3 connections on 3 levels - for actuator
Green/yellow marking for the lower level
Metal base. Screwless fixing on rail
50
0371 52
(1)
Grey
2 . 5
0 . 25 to 4 0 . 25 to 2 . 5 5
Disconnect for measurement
1 connection
With its accessories, allows intervention
(measurements, maintenance, etc) on a current,
voltage and power measuring circuit by keeping the
current transformer secondary circuit closed
Colour
Nominal
cross-section
(mm²)
Capacity
Width (mm)
Rigid cable
(mm
2
)
Flexible
cable (mm
2
)
25
0371 92
Grey
4 0 . 25 to 4 0 . 25 to 4 8
Blade type levers, joining rods and blown
fuse indicators
(p. 19)
NEW
