SCREW CONNECTION
TERMINAL BLOCKS
Nominal
capacity
(mm
2
)
Width(mm)
Cat. Nos.
(old range)
Cat. Nos.
(new
range)
Standard
1 connection
2 . 5 5 0390 60
0371 60
4 6 0390 61
0371 61
6 8 0390 62
0371 62
10 10 0390 64
0371 63
16 12 0390 66
0371 64
35 15 0390 68
0371 65
70 22 0390 70
0371 66
1 connection - 1 entry - 2 outlets
4 6 0390 82
0371 69
2 connections - 2 levels
2 . 5 5 0390 77
0371 67
4 6 0390 78
0371 68
3 connections - 3 levels
2 . 5 5 0390 51
0371 51
V.O. - UL 94
1 connection
2 . 5 5 0390 00
–
4 6 0390 01 –
6 8 0390 02 –
Function
blocks
2 connections
2 levels
Shunted
4 6 0390 76
0371 69
Diode carrier
4 6 0390 80
0371 55
With voltage
presence LED 4 6 –
0371 56
Disconnect
1 connection
Blade type
4 6 0390 84
0371 84
Neutral
equipped
4 8 0390 85
0371 82
For cartridge
5 x 20
10 12 –
0371 87
4 8 0390 86
0371 81
4 8 –
0371 81
+
037525
2 connections
2 levels
For cartridge
5 x 20
4 8 0390 88 –
old range: Viking 3
terminal blocks and accessories
and equivalences between old/new range
ELECTRICAL
FUNCTION
TERMINAL BLOCK INSULATION EQUIPOTENTIAL
LINK
PROTECTION ASSOCIATED
PRODUCTS
Max.
connection
(mm
2
)
Width
(mm)
Cat. Nos.
Separation
and insulation
divider
Shunt
Cover
4 blocks
Cover
3 blocks
Rail
3
Rail
1
Power
terminal
blocks
(p. 24)
Cable - cable
42 0390 10 –
–
0394 46
–
–
55 0390 11 –
–
0394 47
–
–
Cable lug -
Cable lug
36 0390 13 –
–
0394 46
–
–
42 0390 14 –
–
0394 46
–
–
55 0390 15 –
–
0394 47
–
–
Cable lug -
Cable
42 0390 17 –
–
0394 46
–
–
55 0390 18 –
–
0394 47
–
–
Cable -
Cable lug
42 0390 20 –
–
0394 46
–
–
55 0390 21 –
–
0394 47
–
–
For busbars
or eyelets
35
26
0390 71
0390 31 0394 77
–
0394 88 –
70
34
0390 72
0390 32 0394 78
–
0394 86 –
120 34
0390 73
0390 33 0394 78
–
0394 86 –
240 46
0390 74
0390 34 0394 78
–
0394 89 0394 86
Red catalogue numbers: New products
Viking 3
heavy duty terminal blocks
0390 21
0390 11
0390 14
CAB 3
(p.
27
)
SCREW CONNECTION (CONTINUED)
TERMINAL BLOCKS
Nominal
capacity
(mm
2
)
Width(mm)
Cat. Nos.
(old range)
Cat. Nos.
(new
range)
For neutral
conductor
1 connection
2 . 5 5 0393 00
0371 00
4 6 0393 01
0371 01
6 8 0393 02
0371 02
10 10 –
0371 03
16 12 0393 04
0371 04
35 15 –
0371 05
2 connections - 2 levels
4 6 0393 07
0371 08
For circuit
not broken
1 connection
2 . 5 5 –
0371 20
4 6 0393 39
0371 21
1 disconnect connection
4 6 0393 38
0371 85
For sensor/
actuator
3 connections
3 levels
Sensor/power supply unit 2 . 5 5 0390 51
0371 51
Actuator/power supply unit
2 . 5 5 0390 52
0371 52
PNE
Phase/Neutral/Earth
For special
circuits
1 connection - red
2 . 5 5 –
0371 30
1 connection - red
4 6 –
0371 31
For
protection
conductor
1 connection - Metal base
2 . 5 5 0371 70
0371 70
4 6 0371 71
0371 71
6 8 0393 72
0371 72
10 10 0393 74
0371 73
16 12 0393 76
0371 74
35 15 0393 78
0371 75
2 connections - 2 levels - Metal base 4 6 0393 73
0371 79
1 connection - Plastic base
4 6 0393 81
0371 77
6 8 0393 82
0371 78
1 connection - Metal base - bare
terminal
35 15 –
0371 76
