Red catalogue numbers: New products
Viking 3
accessories for terminal blocks (continued)
(1) Except for Cat. No. 0371 87
(2) Except for disconnect blocks with handle lever, screw terminal
block with LED and spring function blocks. 2 and 3-level terminal
blocks: upper level only
Pack
Cat. Nos.
Equipotential bridging accessories (continued)
Bars for screw terminal blocks
Front mounting with screws. Pre-assembled
Consecutive or alternating connection
10
0375 40
For 12 blocks with 10 mm width
10
0375 42
(1)
For 12 blocks with 12 mm width
10
0375 44
For 12 blocks with 15 mm width
Bridging combs for 3-level screw terminal blocks
For lower and intermediate levels of blocks
Cat. Nos. 0371 51/52. Side mounting
Isolated and separable
10
0375 46
Brown. For 12 blocks with 5 mm width
10
0375 47
Blue. For 12 blocks with 5 mm width
Bridging combs for spring terminal blocks
Front mounting (automatic insertion), screwless
Isolated. Red
20
0375 82
For 2 blocks with 10 mm width
20
0375 85
For 2 blocks with 12 mm width
Accessories for disconnect blocks
For screw and spring terminal blocks
Blade type levers
For open blocks Cat. Nos. 0371 80 and 0372 80
Manual disconnection for handle type, tool required
for mini lever type
10
0375 15
With handle lever for fuse cartridge 5 x 20
10
0375 16
Blue handle lever for neutral
10
0375 17
Grey handle lever
10
0375 18
Mini lever
Joining rods
For handle and mini lever
20
0375 21
For 2 blocks
20
0375 22
For 3 blocks
Blown fuse indicators
Clip directly on to blocks Cat. Nos. 0371 81,
0372 81 or handle lever 0375 15 (with power off)
10
0375 24
12/24/48 V
=
/
A
for block with
fuse cartridge 5 x 20 with handle lever
10
0375 25
110/250 V
A
for block with fuse cartridge
5 x 20 with handle lever
Shielding accessories
Ensure safe, simple connection of cable shielding
Shielding clamps
For screw and spring terminal blocks
- mounted by pivoting on collector bar
10 x 3 mm Cat. No. 0375 34
- mounted on plate with M4 screws (supplied)
- mounted on rail
4
with Cat. No. 0364 69
10
0375 30
For cable diameter 3 to 8 mm
10
0375 31
For cable diameter 4 to 13 . 5 mm
4
0375 32
For cable diameter 10 to 20 mm
Pack
Cat. Nos.
Shielding accessories (continued)
Ensure safe, simple connection of cable shielding
Shielding bar
For screw and spring terminal blocks. Steel. Length
1 m. For use with end stops Cat. No. 0375 12
10
0375 34
10 x 3 mm
Screening continuity bracket
50
0375 35
For screw terminal blocks 1 entry/1 outlet
5, 6, 8 and 10 mm width
Connected with 2 . 8 x 0 . 8 mm clips
or welded on. Capacity: 1 mm
2
Protective screens
1 pole
For screw terminal blocks 1 entry/1 outlet
10
0375 65
5 and 6 mm width
10
0375 66
8 and 10 mm width
10
0375 67
12 and 15 mm width
Cut to length
Length 1 m
Mounted on separation and insulation divider
For screw terminal blocks 1 entry/1 outlet
10
0375 68
5, 6, 8 and 10 mm width
(divider Cat. No. 0375 60)
10
0375 69
12 and 15 mm width
(divider Cat. No. 0375 61)
Measurement accessories
For screw and spring terminal blocks
10
0375 27
(2)
Measurement socket for Ø4 mm plug
for blocks with 5 and 6 mm width
For screw terminal blocks
50
0375 75
Measurement socket for Ø2 mm plug
for blocks with 10 mm width Cat. Nos. 0371 03/63
20
0375 76
Measurement socket for Ø4 mm plug
for blocks with 12 and 15 mm width
Cat. Nos. 0371 04/05/64/65
10
0375 77
Measurement socket for Ø4 mm plug
for disconnect block for measurement
Cat. No. 0371 92
0371 80
+
0375 15
+
0375 25
0372 81
+
0375 24
0375 77
+
0371 92
open
0375 66
+
0371 63
+
0371 03
0375 15
0375 16
0375 17
0375 18
Shielding terminal block with end stops
0375 12
,
bar
0375 34
and clamps
0375 30/31
Technical characteristics (p. 22)
0375 76
+
0371 64
0375 27
+
0371 61
