21 / 36
21
Function blocks
Disconnect block for measurement
Wiring diagram for measurement blocks Cat. No. 0371 92
Blocks for sensors and actuators/PNE
Stripped lengths (mm)
Schematic diagrams
Wiring diagram
IEC 60947-7-1, CSA no. 22-2 no. 158, UL 1059
IEC EN 60947-7-1
IEC 60947-7-1/7-2, CSA no. 22-2 no. 158, UL 1059
Ie: Rated current NF C 15100 table 52H, column 4
Cat. No. 0371 53
Cat. No. 0371 92
Ammeter circuit
Wattmeter circuit
Block for sensor Cat. No. 0371 51
Block for actuator Cat. No. 0371 52
PNE block Cat. No. 0371 52
Cat. No. 0371 56
Cat. Nos. 0371 51/52
Diode for Cat. Nos. 0371 54/55
- 1N4007 type 1A
- direct current
=
1 A
- peak inverse voltage 1000 V
- inverse current 5 µA at 25°C
Cat. Nos. 0371 53/54
Cat. No. 0371 54
Cat. Nos. 0371 55/56
Cat. No. 0371 55
73·2
62
69·5
L1
L2
L3
N
PE
Sensors
Signal
Signal
Automation
Bridging comb
Cat. No. 0375 47
Power supply
(shared)
Power supply
or Ph - N
To
actuators
Signal
Signal
Automation
Bridging comb
Cat. No. 0375 47
common
Phase
Neutral
+
+
-
-
84·5
38·8
67·4
74·9
71·2
65·9
26·8
46·5
54
74·8
72·2
62·5
70
Cat. Nos.
Voltage (V)
Current (A)
Nominal cross-section
IEC CSA UL IEC CSA UL IEC
(mm
2
)
CSA
(AWG)
UL
(AWG)
0371 53
250
-
-
-
-
-
2 . 5
-
-
0371 54
250
-
-
1
-
-
2 . 5
-
-
0371 55
500 300 300
1
1
1
4
10
10
0371 56
12 to 24 12 to 24 12 to 24 32
30
30
4
10
10
Cat. Nos.
Voltage (V)
Current (A)
Nominal cross-
section
IEC CSA UL Ie IEC CSA UL IEC
(mm
2
)
CSA
(AWG)
UL
(AWG)
0371 51
400 300 300 27 24 20 20 2 . 5 12 12
0371 52
Cat. Nos.
Voltage (V)
Current (A)
Nominal cross-section
IEC CSA UL IEC CSA UL IEC
(mm
2
)
CSA
(AWG)
UL
(AWG)
0371 92
800 -
-
24
-
-
4
-
-
Screw terminal width (mm)
Rigid or flexible cable
5
6 to 8
6
8
10 to 12
10
12
13 to 17
15
14 to 18
22
15 to 22
Protection against fire and panic risks in public
buildings/UTE C 12-201 guide
Art. EL 3, definitions: "Security installations are those that have
to be put into or maintained in service to ensure the evacuation
of the public" or facilitate the intervention of the first-aid
Art. EL 16, power supply circuits in security installations section
1a: "…the corresponding junction or deviation devices and their
enclosures except for the waterproofing systems must satisfy
the incandescent cable test defined in the standard in force, the
temperature of the incandescent cable being 960 °C"
Viking 3 terminal blocks satisfy the incandescent cable test 960 °C
according to standard IEC 60695-2-11
Per circuit:
2 x Disconnect blocks for measurement
Cat. No. 0371 92
4 x Measurement sockets for Ø4 mm plug
Cat. No. 0375 77
1 x End cap Cat. No. 0375 57
1 x Shunt with Ø4 mm plugs
10 x Disconnect blocks for measurement
Cat. No. 0371 92
12 x Measurement sockets for Ø4 mm plug
Cat. No. 0375 77
1 x End cap Cat. No. 0375 57
3 x Shunts with Ø4 mm plugs
Normal
position
Test
position
Short-circuit
position
