Starfix
®
ferrules and crimping tools
0376 43
0376 77
0376 87
0376 09
+ refill 0376 43
Adjustable cross-section
0376 39
0376 92
0376 06
0376 66
0376 50
Pack
Cat. Nos.
Ferrules with insulating flange
Provide an equipotential link for all the strands
of a flexible conductor
Active part in tinned electrolytic copper
Conform to NF C 63-023
Single ferrules (in strips)
For cables
cross-section (mm²)
Colour
Strips
Ferrules
500
0376 50
0 . 25
turquoise 10
50
500
0376 60
0 . 34
green
12
40
480
0376 61
0 . 5
white
12
40
480
0376 62
0 . 75
blue
12
40
1 000
0376 63
1
red
25
40
1 000
0376 64
1 . 5
black
25
40
1 000
0376 66
2 . 5
grey
25
40
250
0376 67
4
orange
10
25
250
0376 68
6
green
10
25
Single ferrules (in sachets)
500
0377 50
0 . 25
turquoise
5
100
500
0377 60
0 . 34
green
10
100
480
0377 61
0 . 5
white
10
100
480
0377 62
0 . 75
blue
10
100
1 000
0377 63
1
red
10
100
1 000
0377 64
1 . 5
black
10
100
1 000
0377 66
2 . 5
grey
10
100
250
0377 67
4
orange
10
100
250
0377 68
6
green
5
50
Single ferrules (individual)
100
0376 69
10
brown
100
0376 70
16
white
50
0376 71
25
black
Double ferrules
100
0376 87
2 x 0 . 75
blue
100
0376 88
2 x 1
red
100
0376 89
2 x 1 . 5
black
100
0376 90
2 x 2 . 5
grey
Large capacity Starfix refills
Large capacity for less frequent applicator reloading
Translucent packaging
For direct mounting on crimping tool Cat. No. 0376 09
Cross-section
Colour
Number of ferrules
(mm
2
)
per strip
3 000
0376 41 0 . 5
White
300
3 000
0376 42 0 . 75
Blue
300
3 000
0376 43 1
Red
300
3 000
0376 44 1 . 5
Black
300
2 500
0376 45 2 . 5
Grey
250
Red catalogue numbers: New products
Pack
Cat. Nos.
Crimping tools for ferrules in strips
Cut and carry out 4-point crimping of ferrules from
0 . 25 to 6 mm
2
in one operation
Recommended for spring connections
Dedicated applicator for each crimping tool for
dispensing strips
Starfix crimping tool for 0 . 25 and 0 . 34 mm
2
cross-sections
1
0376 08
Supplied with empty applicator fitted
Starfix crimping tool for 0 . 5 to 2 . 5 mm
2
cross-sections
1
0376 09
Fitted with an adjustment wheel
Supplied with empty applicator fitted
1
0376 39
Assorted kit, comprising:
- 1 Starfix crimping tool, Cat. No. 0376 09 with empty
applicator fitted
- 120 x 0 . 5 mm
2
ferrules
- 120 x 0 . 75 mm
2
ferrules
- 240 x 1 mm
2
ferrules
- 320 x 1 . 5 mm
2
ferrules
- 200 x 2 . 5 mm
2
ferrules
Starfix crimping tool for 4 and 6 mm
2
cross-sections
1
0376 10
Fitted with an adjustment wheel
Supplied complete with empty applicator
Starfix S multi-purpose crimping tool for 0 . 5 to
2 . 5 mm
2
cross-sections
1
0376 97 Tool cuts, strips, twists, crimps
Supplied complete with 5 empty applicators
For left and right-handed usage
Crimping tool for single and double ferrules
Starfix crimping tool for 0 . 25 to 6 mm
2
cross-sections
For 4-point crimping of ferrules from 0 . 25 to 6 mm
2
Recommended for spring connections
1
0376 06
Crimping tool with disengageable control system,
crimping at end
Right or left-handed
Starfix clamp for 10 to 50 mm
2
cross-section
1
0376 92 Assorted kit. Supplied with:
- 1 tool with crimping operation control system for
individual ferrules 10 to 50 mm
2
- 30 individual ferrules 10 mm
2
- 20 individual ferrules 16 mm
2
- 15 individual ferrules 25 mm
2
- 10 individual ferrules 35 mm
2
- 10 individual ferrules 50 mm
2
