29 / 36
29
CAB 3
®
marking system
for cables and Viking 3 terminal blocks
CAB 3
®
marking system
accessories
0383 92 +
CAB 3 markers
0382 00
0383 97
0384 90
0384 92
Pack
Cat. Nos.
CAB 3 accessories
Marker holders
For cables cross-section from 10 mm
2
to 70 mm
2
Capacity:
8 digits, letters or symbols markers from 0 . 5 to
1 . 5 mm
2
or 1 . 5 to 2 . 5 mm
2
cross section
Black, cross-section (mm
2
)
100
0384 90 10 to 16
50
0384 91 25 to 35
50
0384 92 50 to 70
Support for markers
100
0383 92 Can be clipped on to Viking 3 terminal blocks
Capacity:
7 markers from 0 . 15 to 0 . 5 mm
2
6 markers from 0 . 5 to 1 . 5 mm
2
Transparent applicators
For rapid selection and application of markers on to
cable
For markers
Applicator colour for
cross-section (mm
2
) identification of cross-section
10
0383 94 0 . 15 to 0 . 5
CAB 3
10
0383 95 0 . 5 to 1 . 5
CAB 3
10
0383 96 1 . 5 to 2 . 5
CAB 3
10
0383 97
4 to 6
CAB 3
Set of markers
1
0382 01 0 . 15 to 0 . 5 mm
2
: 2 500 markers
+ 10 applicators (250 digits from 0 to 9)
1
0382 02 0 . 5 to 1 . 5 mm
2
: 3 000 markers
+ 10 applicators (300 digits from 0 to 9)
1
0382 03 1 . 5 to 2 . 5 mm
2
: 3 000 markers
+ 10 applicators (300 digits from 0 to 9)
1
0382 04 4 to 6 mm
2
: 2 000 markers
+ 10 applicators (200 digits from 0 to 9)
On-site toolbox
1
0382 00 With removable tray for CAB 3 markers and
applicators, Starfix ferrules etc.
Height 85 mm, depth 280 mm, width 450 mm
Metal, padlockable
Dimensions
Cable cross-section (mm
2
)
0 . 15 to 0 . 5 0 . 5 to 1 . 5 1 . 5 to 2 . 5 4 to 6
A (mm)
5
5
5 . 6
8
B (mm)
5 . 05
6 . 4
7 . 6
9 . 6
C (mm)
3 . 7
4 . 3
4 . 9
7 . 1
D (mm)
2 . 3
3
3
3
Ø min./max. (mm)
0 . 8/2 . 2
2 . 2/3
2 . 8/3 . 8
4 . 3/5 . 3
B
A
D
C
450
280
85
Marker holders
■
Characteristics and dimensions of on-site toolbox
Cat. No. 0382 00
Bottom tray consists of:
•
8 medium slots
(each slot takes 1 box of CAB 3)
•
1 large slot
Top tray consists of:
•
12 small slots (
<
=
>
approx.
6 boxes of CAB 3)
•
1 medium slot for applicators
Capacity: approx. 15000 CAB 3 markers
B
C
D
26·3
26·3
26·3
Cat. No. 0384 90 Cat. No. 0384 91 Cat. No. 0384 92
■
Dimensions
Markers
Polyamide 6/6
Dim.
Section of cable for marking (mm
2
)
10 to 16
25 to 35
50 to 70
A (mm)
18
24 . 3
27 . 2
B (mm)
8 . 9
12 . 2
17 . 2
C (mm)
7
7
10
Support for markers Cat. No. 0383 92
18
10·7
5
On cable with marker holder
Cat. No. 0384 92
On heavy duty terminal blocks
On terminal blocks,
with label holder
Cat. No. 0383 92
