Contactors and Override Contactors
Description
Modular contact
Auxiliary
contact
Standard conformity
EN 61095
Approvals
NF - VDE- IMQ - KEMA - RMC / CCC
Relay
Contactor Relay
Contactor Contactor Contactor Contactor
Number of modules
1
2
3
½
Thermal current lth (40ºC)
16A
25A
16A
25A
40A
63A
6A
Rated frequency
50 - 60 Hz 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
Rated insulation voltage (Ui)
250V
250V
440V
440V
440V
440V
250V
Rated impulse withstand voltage (Uimp)
4kV
4kV
4kV
4kV
4kV
4kV
4kV
Protection Degree
2
2
2
2
2
2
2
Rated Operating currents and power ratings in AC
AC-1 / AC-7a
Rated operational currents Ie
16A
16A
16A
25A
40A
63A
-
Rated operational power
230V
3kW 4.6kW 3kW 4.6kW 7.3kW 11.6kW -
400V
-
-
8.9kW 13.8kW 22kW 35kW -
AC-3 / AC-7b Rated operational currents Ie
5.5A
8.5A
5.5A
8.5A
25A
32A
-
Rated operational power
230V
570W 880W 570W 880W 2.6kW 3.3kW -
400V
-
-
1.7kW 2.6kW 7.8kW 10kW -
AC-12
Rated operational currents Ie @
230V
-
-
-
-
-
-
6A
AC-15
Rated operational currents Ie @
230V
-
-
-
-
-
-
2A
Mechanical and Electrical Endurances
Mechanical endurance
Number of
operations 1,000,000 1,000,000 1,000,000 1,000,000 1,000,000 1,000,000 1,000,000
Electrical endurance @ Ie AC7a (AC12
for aux contact)
Number of
operations 60,000 60,000 60,000 60,000 60,000 60,000 60,000
MCB Protected short-circuit withstand
Prospected short-circuit current
rms
1kA
3kA
1kA
3kA
3kA
3kA
1kA
Associated protection
MCB C16-6kA MCB C25-6kA MCB C16-6kA MCB C25-6kA
MCB C40-
10kA
MCB C63-
10kA
6A 10x38 gG
Fuse
Power dissipation
Power dissipation per current path
1W 1.5W 1W 1.5W 3.2W 5W 0.4W
Magnetic system for Eco and standard contactor
Pick-up
2.2W 2.2W 2.8W 2.8W 5W 5W -
Coil consumption
2.2W 2.2W 2.8W 2.8W 5W 5W -
Closing delay
25ms
25ms
25ms
25ms
25ms
25ms
-
Opering delay
15ms
15ms
15ms
15ms
20ms
20ms
-
Connection
Main contact cable section
Rigid
1...10mm
2
1...10mm
2
1...10mm
2
1...10mm
2
4...25mm
2
4...25mm
2
1...6mm
2
Flexible 1...6mm
2
1...6mm
2
1...6mm
2
1...6mm
2
4...16mm
2
4...16mm
2
1...6mm
2
Main contact connection screw
Type
M3.4
M3.4
M3.4
M3.4
M5
M5
M3.4
Posidrive PZ2
PZ2
PZ2
PZ2
PZ2
PZ2
PZ2
Max. tight.
torque 1.2Nm 1.2Nm 1.2Nm 1.2Nm 2Nm 2Nm 1.2Nm
Coil connection cable section
Rigid
1...10mm
2
1...10mm
2
1...10mm
2
1...10mm
2
1...10mm
2
1...10mm
2
-
Flexible 1...6mm
2
1...6mm
2
1...6mm
2
1...6mm
2
1...6mm
2
1...6mm
2
-
Coil connection screw
Type
M3.5
M3.5
M3.5
M3.5
M4
M4
-
Posidrive PZ2
PZ2
PZ2
PZ2
PZ2
PZ2
-
Max. tight.
torque 1.2Nm 1.2Nm 1.2Nm 1.2Nm 1.5Nm 1.5Nm -
Working temperature
-10ºC to +50ºC
Storage temperature
-40ºC to +80ºC
