5.33
Dimmers
Description
Hager dimmers control the
lighting level of all types of
lighting source: incandescent,
LV halogen, ELV halogen with
electronic or ferromagnetic
transformer, LED ELV lamps
with electronic transformer,
fluorescent with electronic
ballast.
The EVN 300W and 500W
dimmers also allow lighting level
adjustment for dimmable CFL
and dimmable LED lamps.
Dimming controlled by push
button:
• Start / stop by short press
• Increasing / decreasing by
maintaining pressure
Common characteristics
• Universal dimmers with
automatic load recognition
• Softstart (progressive start)
to increase the working life of
lamps
• Memorisation of last dimming
level
• Protection against overheating
For technical details see page
5.70.
1 Mod = 17.5mm
2 Mod = 35mm
Universal Dimmers 300W
• Compatible with dimmable CFL and LED
• 3 modes for load learning: auto, advanced, expert (comfort version)
• Can replace a latching relay, with lighting level function
• Push button (line or neutral).
• Very low consumption.
Characteristics
Width
Cat ref.
Standard version
1
EVN011
Comfort version
• Expert mode
1
EVN012
• Scene by 2 short double presses
on the PB (progressive switch-
off, night light, 100%, no function)
Universal Dimmers 500W
• Compatible CFL and LED
• 3 modes for load learning: auto, advanced, expert (comfort version)
• Very low consumption
Characteristics
Width
Cat ref.
Standard version
2
EVN002
Comfort version
• Expert mode
2
EVN004
• 100% via 2 short preses on the
dim input PB
• One scene PB (scene, time-
delayed scene, progressive
switch-off, night light)
• Multi-voltage dim PB
EVN011
EVN004
Modular
Devices
