5/80 Contactor for capacitors, contactor
Actuating voltages
2010 CA08103002Z-EN
AC DILK12-11
(...)
DILK20-11
(...)
DILK25-11
(...)
DILK33-10
(...)
DILK50-10
(...)
Article no.1) Article no.1) Article no.1) Article no. 1) Article no.1)
Standard voltages See price list See price list See price list See price list See price list
110V 50Hz,
120V 60Hz
293985 294007 294029 294051 294073
190V 50Hz,
220V 60Hz
293986 294008 294030 294052 294074
230V 50Hz,
240V 60Hz
293988 294010 294032 294054 294076
400V 50Hz,
440V 60Hz
293990 294012 294034 294056 294078
Special voltages other than the already
shown normal voltages 2)
See price list See price list See price list
…V 50Hz (24 – 600V) 3) 293997 294019 294041 – –
…V 60Hz (24 – 600V) 3) 293998 294020 294042 – –
Notes 1) The article no. results from combining the part no. and the actuating voltage.
Devices with dual-voltage coils must be ordered under a single article no.
2) With non-standard voltages the required actuating voltage from the defined range (...–...V) must be stated.
3) Minimum order quantity 10 units
Contactors up to 150 A with electronic actuation
AC DILMF8-10 (…) DILMF8-01 (…) DILMF11-10
(…)
DILMF11-01
(…)
DILMF14-10
(…)
DILMF14-01
(…)
DILMF17-10
(…)
Article no.1) Article no. 1) Article no.1) Article no. 1) Article no.1) Article no.1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list See price list
RAC 241) 104410 104414 104418 104422 104426 104430 104434
RAC 483) 104411 104415 104419 104423 104427 104431 104435
RAC 1204) 104412 104416 104420 104424 104428 104432 104436
RAC 2405) 104413 104417 104421 104425 104429 104433 104437
AC DILMF17-01
(…)
DILMF25-10
(…)
DILMF25-01
(…)
DILMF32-10
(…)
DILMF32-01
(…)
DILMF40 (…) DILMF50 (…)
Article no.1) Article no. 1) Article no.1) Article no. 1) Article no.1) Article no.1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list See price list
RAC 242) 104438 104442 104446 104450 104454 104458 104462
RAC 483) 104439 104443 104447 104451 104455 104459 104463
RAC 1204) 104440 104444 104448 104452 104456 104460 104464
RAC 2405) 104441 104445 104449 104453 104457 104461 104465
AC DILMF65 (…) DILMF80 (…) DILMF95 (…) DILMF115 (…) DILMF150 (…)
Article no.1) Article no. 1) Article no.1) Article no. 1) Article no.1)
Standard voltages See price list See price list See price list See price list See price list
RAC 242) 104466 104470 104474 104478 104482
RAC 483) 104467 104471 104475 104479 104483
RAC 1204) 104468 104472 104476 104480 104484
RAC 2405) 104469 104473 104477 104481 104485
Notes 1) The article no. results from combining the part no. and the actuating voltage.
2) 24 - 24 V
3) 42 - 48
4) 100 - 120
5) 190 - 240
DILK, DILMF HPL05080EN
