Contactors

Enclosures

2010

CA08103002Z-EN

5/83

DILE, DILM, SDAINL, DIUL

Components

Contactor selection

With top mounting

auxiliary contacts

With side mounting

auxiliary contacts

With overload relay With parallel

connector

Part no.

Insulated

enclosures

DILE...(-G)(-C)

–

–

–

–

CI-K1-95-TS

DILE...(-G)(-C)

•

–

–

–

CI-K2-145-TS

DILE...(-G)

•

–

•

–

CI-K2-145-AD

DILE...(-G)

–

–

–

•

CI-K2-100-TS

DILE...(-G)

•

–

–

•

CI-K2-145-TS

DILM7 to DILM15

•

–

–

–

CI-K2-145-TS

DILM7 to DILM15

•

–

•

–

CI-K3-160-TS

DILM17 to DILM32

–

–

–

–

CI-K2-145-TS

DILM17 to DILM32

•

–

•

–

CI23E-150

DILM40 to DILM65

–

•

–

–

CI-K3-160-TS

DILM40 to DILM65

•

•

•

–

CI43E-150

DILM80 to DILM170

•

•

–

–

CI43E-200

DILM80 to DILM170

•

•

•

–

CI44E-200

DILM185A

–

•

–

–

CI48-250

DILM225A

–

•

–

–

CI48-250

DILM250

–

•

–

–

CI48-250

DILM300A

–

•

–

–

CI48-250

DILM400

–

•

–

–

CI48-250

DILM500

–

•

–

–

CI48-250

DILM580

–

•

–

–

CI48-250

DILM650

–

•

–

–

CI48-250

DILM750

–

•

–

–

CI48-250

DILM820

–

•

–

–

CI48-250

DIULE...

•

–

–

–

CI-K3-125-TS

DIULE...

•

–

•

–

CI-K3-125-TS

DIULM7 to DIULM12

•

–

–

–

CI-K4-160-TS

DIULM17 to DIULM32

•

–

–

–

CI23E-150

DIULM40 to DIULM65

•

–

–

–

CI43E-200

SDAINLEM...

•

–

–

–

CI-K5-125-TS

CI-K5-125-M

SDAINLM12 to SDAINLM22

•

–

–

–

CI-K5-160-TS

SDAINLM30 to SDAINLM65

•

–

–

–

CI23E-150

SDAINLM70 to SDAINLM115

•

–

–

–

CI43E-200

Notes

CI-K small

enclosure

￫Chapter 20

Insulated PE, N or

PEN terminal for

enclosure CI-K

￫Chapter 20

Terminal for CI-K

enclosure

￫Chapter 20

CI enclosure

￫Chapter 20
