5/84 Contactors
UL/CSA-approved rating data
2010 CA08103002Z-EN
for North America
DILE, DILA, DILM
Rating data for approved types Contactors
GENERAL USE
Maximum
alternating current-
motor rating
Maximum
motor-
rated current
Single-phase 3-phase Ith
Open/enclosed
NEMA size
115 V
120 V
230 V
240 V
200 V
208 V
230 V
240 V
460 V
480 V
575 V
600 V
HP HP HP HP HP HP A Part no.
½ 1½ 2 3 5 5 15/13.5 DILEM(4) 00
¼ 1 1½ 2 3 5 20 DILM7-...(...) 00
½ 1½ 3 3 5 7½ 20 DILM9-...(...) 00
1 2 3 3 10 10 20 DILM12-...(...) 0
1 3 5 10 10 20 DILM15-...(...) 0
2 3 5 7½ 10 15 35 DILM17-...(...) 0
2 5 7½ 7½ 15 20 35 DILM25-...(...) 1
3 5 10 10 20 25 40 DILM32-...(...), DILM38-...(...) 1
3 7½ 10 15 30 40 55 DILM40(...) 2
3 10 15 20 40 50 65 DILM50(...) 2
5 15 20 25 40 60 80 DILM65(...), DILM70(...) 2
7½ 15 25 30 60 75 125 DILM80(...) 3
7½ 15 25 40 75 100 125 DILM95(...) 3
10 25 40 50 100 125 160 DILM115(...) 4
15 30 40 60 125 125 160 DILM150(...), DILM170(...) 4
– – 50 60 125 150 225 DILM185(...) 4
– – 60 75 150 200 250 DILM225(...) 4
– – 75 100 200 250 350 DILM250(...) 5
– – 100 125 250 300 350 DILM300(...) 5
– – 125 150 300 400 450 DILM400(...) 5
– – 150 200 400 500 550 DILM500(...) 6
– – 200 200 400 600 630 DILM580(...) 6
– – 200 250 500 600 700 DILM650(...) 6
– – 250 300 600 700 800 DILM750(...) 6
– – 290 350 700 860 850 DILM820(...) 6
– – 350 400 800 1000 1000 DILM1000(...) 7
– – 560 640 1200 1300 1600 DILM1600(...) 8
Further approvals￫ 5/85
• Elevator control
• Refrigeration control
• Resistance air heating
• Incandescent lamps
• Electrical discharge lamps
• Capacitive switching
Approved rating data
UL -File No. E29184
for auxiliary contacts
Pilot Duty General Use
AC DC AC DC
Part no. V A V A
DIL(E)EM-10(-01)
DILER-40(31)(22)
...(D)DILE
A600 P300 600 10 250 0.5
DILM7-10(-01)
To
DILM32-10(-01)
DILA...
A600 P300 600 15 250 1
DILA-XHI...
DILM32-XHI...
A600 P300 600 15 250 1
DILM...-XHI11-SI
DILM...-XHI11-SA
DILM...-XHI11V-SI
A600 P600 600 10 – –
