Contactors

Actuating voltages

2010

CA08103002Z-EN

5/79

AC

DILM32-XSP

(...)

DILM65-XSP

(...)

DILM95-

XSP

Article no.

1)

Article no.

1)

Article no.

1)

Standard voltages

See price

list

See price

list

See price

list

24

V 50Hz

281130

281160

229984

240

V 50Hz

281132

281162

229986

24

V 60Hz

281134

281164

229988

115

V 60Hz

281136

281166

229990

42

V 50Hz

48

V 60Hz

281137

281167

229994

110

V 50Hz

120

V 60Hz

281138

281168

230058

190

V 50Hz

220

V 60Hz

281139

281169

230059

220

V 50Hz

240

V 60Hz

281140

281170

230061

230

V 50Hz

240

V 60Hz

281141

281171

230062

380

V 50Hz

440

V 60Hz

281142

281172

230063

400

V 50Hz

440

V 60Hz

281143

281173

230064

415

V 50Hz

480

V 60Hz

281144

281174

230065

24

V 50Hz/60Hz

281145

281175

230066

42

V 50Hz/60Hz

281146

281176

230067

110

V 50Hz/60Hz

281147

281177

230068

220

V 50Hz/60Hz

281148

281178

230073

230

V 50Hz/60Hz

281149

281179

230074

Special voltages

other than the already

shown normal-

voltages

2)

See price

list

See price

list

See price

list

...

V 50Hz

(24 – 600

V)

281153

13)

281183

14)

230078

14)

...

V 60Hz

(24 – 600

V)

281154

13)

281184

14)

230079

14)

DC

DILM32-XSP

(...)

DILM65-XSP

(...)

DILM95-

XSP

Article no.

1)

Article no.

1)

Article no.

1)

Standard voltages

See price

list

See price

list

See price

list

RDC 24

3)

281155

281185

230080

RDC 60

4)

281156

281186

230081

RDC 130

5)

281157

281187

230082

RDC 240

6)

281158

281188

230107

AC

DILM150-XSP

(...)

DILM225A-XSP

(...)

Article no.

1)

Article no.

1)

Standard voltages

See price

list

See price list

RAC 24

7)

230109

139562

RAC 48

8)

230110

139563

RAC 120

9)

230111

139564

RAC 240

10)

230112

139565

RAC 440

11)

230113

139566

RAC 500

12)

230114

139567

DC

DILM150-XSP

(...)

DILM225A-XSP

(...)

Article no.

1)

Article no.

1)

Standard voltages

See price

list

See price

list

RDC 24

3)

230115

139568

RDC 60

4)

230116

139569

RDC 130

5)

230117

139570

RDC 240

6)

230122

139571

Notes

1)

To obtain the article number for ordering, read under

selected part number and actuating voltage from the

table.

Devices with dual-voltage coils are to be ordered

under a single article number.

2)

With non-standard voltages the required actuating

voltage from the defined range (...–...V)

must be stated.

3)

24 – 27

V DC

4)

48 – 60

V DC

5)

110 – 130

V DC

6)

200 – 240

V DC

7)

24

V 50/60 Hz

8)

42 – 48

V 50/60 Hz

9)

100 – 120

V 50/60 Hz

10)

190 – 240

V 50/60 Hz

11)

380 – 440

V 50/60 Hz

12)

480 – 500

V 50/60 Hz

13)

Minimum order quantity 10 units

14)

Minimum order quantity 5 units

HPL05079EN

DILM...XSP...
