Eaton Industrial Switchgear - xStart switching, protections and actuating motors

81 / 439

Contactors
Actuating voltages
2010 CA08103002Z-EN
5/77
AC DILMC7-10
(...)
DILMC7-01
(...)
DILMC9-10
(...)
DILMC9-01
(...)
DILMC12-10
(...)
DILMC12-01
(...)
DILMC15-10
(...)
DILMC15-01
(...)
Article no. 1) Article no. 1) Article no. 1) Article no. 1) Article no. 1) Article no. 1) Article no.1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list See price list See price list
24 V 50 Hz 277379 277411 277443 277475 277507 277539 293938 293933
110V 50Hz
120V 60Hz 277386 277418 277450 277482 277514 277546 293908 293943
230V 50Hz
240V 60Hz 277389 277421 277453 277485 277517 277549 293911 293946
24V 50Hz/60Hz 277393 277425 277457 277489 277521 277553 293915 293950
230V 50Hz/60Hz 277397 277429 277461 277493 277525 277557 293919 293954
Special voltages
other than the already
shown normal voltages 2)
See price list See price list See price list See price list See price list See price list See price list See price list
...V 50Hz (12 – 600V)6) 277401 277433 277465 277497 277529 277561 293923 293958
...V 60Hz (12 – 600V)6) 277402 277434 277466 277498 277530 277562 293924 293959
DC DILMC7-10
(...)
DILMC7-01
(...)
DILMC9-10
(...)
DILMC9-01
(...)
DILMC12-10
(...)
DILMC12-01
(...)
DILMC15-10
(...)
DILMC15-01
(...)
Article no. 1) Article no. 1) Article no. 1) Article no. 1) Article no. 1) Article no. 1) Article no.1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list See price list See price list
24V DC 277404 277436 277468 277500 277532 277564 293926 293961
110V DC 277407 277439 277471 277503 277535 277567 293929 293964
220V DC 277408 277440 277472 277504 277536 277568 293930 293965
Special voltages
other than the already
shown normal voltages 2)
See price list See price list See price list See price list See price list See price list See price list See price list
...VDC (12 – 250V)6) 277409 277441 277473 277505 277537 277569 293931 293966
AC DILMC17-10 (...) DILMC17-01(...) DILMC25-10 (...) DILMC25-01 (...) DILMC32-10 (...) DILMC32-01 (...)
Article no. 1) Article no. 1) Article no.1) Article no. 1) Article no. 1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list
24 V 50 Hz 277570 277600 277630 277660 277690 277720
110V 50Hz
120V 60Hz 277578 277608 277638 277668 277698 277728
230V 50Hz
240V 60Hz 277581 277611 277641 277671 277701 277731
24V 50Hz/60Hz 277585 277615 277645 277675 277705 277735
220V 50Hz/60Hz 277588 277618 277648 277678 277708 277738
230V 50Hz/60Hz 277589 277619 277649 277679 277709 277739
Special voltages
other than the already
shown normal voltages2)
See price list See price list See price list See price list See price list See price list
...V 50Hz (24 – 600V)6) 277593 277623 277653 277683 277713 277743
...V 60Hz (24 – 600V)6) 277594 277624 277654 277684 277714 277744
DC DILMC17-10 (...) DILMC17-01 (...) DILMC25-10 (...) DILMC25-01 (...) DILMC32-10 (...) DILMC32-01 (...)
Article no. 1) Article no. 1) Article no.1) Article no. 1) Article no. 1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list
RDC 243) 277595 277625 277655 277685 277715 277745
RDC 1304) 277597 277627 277657 277687 277717 277747
RDC 2405) 277598 277628 277658 277688 277718 277748
Notes 1) The article no. results from combining the part no. and the actuating voltage.
Devices with dual-voltage coils must be ordered under a single article no.
2) With non-standard voltages the required actuating voltage from the defined range (...–...V)
must be stated.
3) 24 - 27 V DC
4) 110 - 130 V DC
5) 200 - 240 V DC
6) Minimum order quantity 10 units
DILM HPL05077EN
