5/72 Contactor relays
Actuating voltages
2010 CA08103002Z-EN
AC With screw terminals With Spring-loaded terminals
DILA-40(...) DILA-31(...) DILA-22(...) DILAC-40(...) DILAC-31(...) DILAC-22(...)
Article no.1) Article no. 1) Article no.1) Article no. 1) Article no. 1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list
24V 50Hz 276316 276351 276386 276431 276463 276495
240V 50Hz 276318 276353 276388 – – –
110V 50Hz
120V 60Hz 276326 276361 276396 276438 276470 276502
190V 50Hz
220V 60Hz 276327 276362 276397 – – –
220V 50Hz
240V 60Hz
276328 276363 276398 – – –
230V 50Hz
240V 60Hz
276329 276364 276399 276441 276473 276505
380V 50Hz
440V 60Hz 276330 276365 276400 – – –
400V 50Hz
440V 60Hz 276331 276366 276401 – – –
24V 50Hz/60Hz 276333 276368 276403 276445 276477 276509
42V 50Hz/60Hz 276334 276369 276404 – – –
110V 50Hz/60Hz 276335 276370 276405 – – –
220V 50Hz/60Hz 276336 276371 276406 – – –
230V 50Hz/60Hz 276337 276372 276407 276449 276481 276513
Special voltages
other than the already
shown normal voltages 2)
See price list See price list See price list See price list See price list See price list
...V 50Hz(12-500V)3) 276341 276376 276411 276453 276485 276517
...V 60Hz(12-600V)3) 276342 276377 276412 276454 276486 276518
DC With screw terminals With Spring-loaded terminals
DILA-40(...) DILA-31(...) DILA-22(...) DILAC-40(...) DILAC-31(...) DILAC-22(...)
Article no.1) Article no. 1) Article no.1) Article no. 1) Article no. 1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list
24V DC 276344 276379 276414 276456 276488 276520
48V DC 276345 276380 276415 – – –
110V DC 276347 276382 276417 276459 276491 276523
220V DC 276348 276383 276418 276460 276492 276524
Special voltages
other than the already
shown normal voltages 2)
See price list See price list See price list See price list See price list See price list
...V DC(12-250V) 3) 276349 276384 276419 276461 276493 276525
Notes 1) The article number is a combination of part no. and operating voltage devices with dual-voltage coils can be
ordered under a single article no.
2) With non-standard voltages the required actuating voltage from the defined range (...–...V) must be stated.
3) Minimum order quantity 10 units
DILA HPL05072EN
