Contactors
Actuating voltages
2010 CA08103002Z-EN
5/75
AC DILM40(...) DILM50(...) DILM65(...) DILM72(...)
Article no. 1) Article no. 1) Article no.1) Article no.1)
Standard voltages See price list See price list See price list See price list
24V 50Hz 277753 277817 277881 –
240V 50Hz 277755 277819 277883 109183
42V 50Hz
48V 60Hz 277762 277826 277890 –
110V 50Hz
120V 60Hz 277763 277827 277891 109191
190V 50Hz
220V 60Hz 277764 277828 277892 –
220V 50Hz
240V 60Hz
277765 277829 277893 –
230V 50Hz
240V 60Hz 277766 277830 277894 107670
380V 50Hz
440V 60Hz 277767 277831 277895 –
400V 50Hz
440V 60Hz
277768 277832 277896 109195
415V 50Hz
480V 60Hz 277769 277833 277897 –
24V 50Hz/60Hz 277770 277834 277898 109197
42V 50Hz/60Hz 277771 277835 277899 –
110V 50Hz/60Hz 277772 277836 277900 109199
220V 50Hz/60Hz 277773 277837 277901 109200
230V 50Hz/60Hz 277774 277838 277902 109201
Special voltages other than the already shown normal voltages 2) See price list See price list See price list See price list
...V 50Hz (24 – 600V) 277778 8) 277842 8) 277906 8) 109205 7)
...V 60Hz (24 – 600V) 277779 8) 277843 8) 277907 8) 109206 7)
DC DILM40(...) DILM50(...) DILM65(...) DILM72(...)
Article no. 1) Article no. 1) Article no.1) Article no.1)
Standard voltages See price list See price list See price list See price list
RDC 24 3) 277780 277844 277908 107671
RDC 60 4) 277781 277845 277909 –
RDC 130 5) 277782 277846 277910 –
RDC 240 6) 277783 277847 277911 109209
Notes 1) To obtain the article number for ordering, read under selected part number and
actuating voltage from the table.
devices with dual-voltage coils can be ordered under a single article no.
2) With non-standard voltages the required actuating voltage from the defined range
(...–...V) must be stated.
3) 24 – 27 V DC
4) 48 – 60 V DC
5) 110 – 130 V DC
6) 200 – 240 V DC
7) Minimum order quantity 10 units
