5/74 Contactors
Actuating voltages
2010 CA08103002Z-EN
AC DILM17-10
(...)
DILM17-01
(...)
DILM25-10
(...)
DILM25-01
(...)
DILM32-10
(...)
DILM32-01
(...)
DILM38-10(...) DILM38-01(...)
Article no. 1) Article no. 1) Article no.1) Article no.1) Article no.1) Article no. 1) Article no. 1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list See price list See price list
24V 50Hz 276991 277023 277119 277151 277247 277279 112378 112446
240V 50Hz 276993 – 277121 – 277249 – 112420 –
42V 50Hz
48V 60Hz 277000 – 277128 – 277256 – 112424 –
110V 50Hz
120V 60Hz
277001 277033 277129 277161 277257 277289 112425 112454
190V 50Hz
220V 60Hz 277002 – 277130 – 277258 – 112426 –
220V 50Hz
240V 60Hz 277003 – 277131 – 277259 – 112427 –
230V 50Hz
240V 60Hz
277004 277036 277132 277164 277260 277292 112428 112457
380V 50Hz
440V 60Hz 277005 – 277133 – 277261 – 112429 –
400V 50Hz
440V 60Hz 277006 277038 277134 277166 277262 277294 112430 112459
415V 50Hz
480V 60Hz
277007 – 277135 – 277263 – 112431 –
24V 50Hz/60Hz 277008 277040 277136 277168 277264 277296 112432 112461
42V 50Hz/60Hz 277009 – 277137 – 277265 – 112433 –
110V 50Hz/60Hz 277010 277042 277138 277170 277266 277298 112434 112463
220V 50Hz/60Hz 277011 277043 277139 277171 277267 277299 112435 112464
230V 50Hz/60Hz 277012 277044 277140 277172 277268 277300 112436 112465
Special voltages
other than the already
shown normal voltages 2)
See price list See price list See price list See price list See price list See price list See price list See price list
...V 50Hz (24 – 600V) 277016 7) 277048 7) 277144 7) 277176 7) 277272 7) 277304 8) 112440 7) 112468 7)
...V 60Hz (24 – 600V) 277017 7) 277049 7) 277145 7) 277177 7) 277273 7) 277305 8) 112441 7) 112469 7)
DC DILM17-10(...) DILM17-01(...) DILM25-10(...) DILM25-01(...) DILM32-10(...) DILM32-01(...) DILM38-10(...) DILM38-01(...)
Article no. 1) Article no. 1) Article no.1) Article no.1) Article no.1) Article no. 1) Article no. 1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list See price list See price list
RDC 24 3) 277018 277050 277146 277178 277274 277306 112442 112470
RDC 60 4) 277019 277051 277147 277179 277275 277307 112443 112471
RDC 130 5) 277020 277052 277148 277180 277276 277308 112444 112472
RDC 240 6) 277021 277053 277149 277181 277277 277309 112445 112473
Notes 1) To obtain the article number for ordering, read under selected part number and actuating voltage from the table.
devices with dual-voltage coils can be ordered under a single article no.
2) With non-standard voltages the required actuating voltage from the defined range (...–...V)
must be stated.
3) 24 – 27 V DC
4) 48 – 60 V DC
5) 110 – 130 V DC
6) 200 – 240 V DC
7) Minimum order quantity 10 units
8) Minimum order quantity 5 units
