Contactors
Actuating voltages
2010 CA08103002Z-EN
5/73
AC DILM7-10
(...)
DILM7-01
(...)
DILM9-10
(...)
DILM9-01
(...)
DILM12-10
(...)
DILM12-01
(...)
DILM15-10
(...)
DILM15-01
(...)
Article no. 1) Article no. 1) Article no.1) Article no.1) Article no.1) Article no.1) Article no. 1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list See price list See price list
24V 50Hz 276537 276572 276677 276712 276817 276852 290045 290080
240V 50Hz 276539 276574 276679 276714 276819 276854 – –
42V 50Hz
48V 60Hz 276546 – 276686 – 276826 – – –
110V 50Hz
120V 60Hz
276547 276582 276687 276722 276827 276862 290055 290090
190V 50Hz
220V 60Hz 276548 276583 276688 276723 276828 276863 – –
220V 50Hz
240V 60Hz 276549 276584 276689 276724 276829 276864 – –
230V 50Hz
240V 60Hz 276550 276585 276690 276725 276830 276865 290058 290093
380V 50Hz
440V 60Hz 276551 276586 276691 276726 276831 276866 – –
400V 50Hz
440V 60Hz 276552 276587 276692 276727 276832 276867 – –
415V 50Hz
480V 60Hz 276553 – 276693 – 276833 – – –
24V 50Hz/60Hz 276554 276589 276694 276729 276834 276869 290062 290097
42V 50Hz/60Hz 276555 276590 276695 276730 276835 276870 – –
110V 50Hz/60Hz 276556 276591 276696 276731 276836 276871 – –
220V 50Hz/60Hz 276557 276592 276697 276732 276837 276872 – –
230V 50Hz/60Hz 276558 276593 276698 276733 276838 276873 290066 290101
Special voltages
other than the already shown
normal voltages 2)
See price list See price list See price list See price list See price list See price list See price list See price list
...V 50Hz (12 – 600V) 3) 276562 276597 276702 276737 276842 276877 290070 290105
...V 60Hz (12 – 600V) 3) 276563 276598 276703 276738 276843 276878 290071 290106
DC DILM7-10
(...)
DILM7-01
(...)
DILM9-10
(...)
DILM9-01
(...)
DILM12-10
(...)
DILM12-01
(...)
DILM15-10
(...)
DILM15-01
(...)
Article no. 1) Article no. 1) Article no.1) Article no.1) Article no.1) Article no.1) Article no. 1) Article no. 1)
Standard voltages See price list See price list See price list See price list See price list See price list See price list See price list
24V DC 276565 276600 276705 276740 276845 276880 290073 290108
48V DC 276566 276601 276706 276741 276846 276881 – –
110V DC 276568 276603 276708 276743 276848 276883 – –
220V DC 276569 276604 276709 276744 276849 276884 – –
Special voltages
other than the already shown
normal voltages2)
See price list See price list See price list See price list See price list See price list See price list See price list
...V DC (12-250V) 3) 276570 276605 276710 276745 276850 276885 290078 290113
Notes 1) To obtain the article number for ordering, read under selected part number and actuating voltage from the table.
devices with dual-voltage coils can be ordered under a single article no.
2) With non-standard voltages the required actuating voltage from the defined range (...–...V)
must be stated.
3) Minimum order quantity 10 units
DILM HPL05073EN
