Contactors
Contact travel diagrams
2010
CA08103002Z-EN
www.eaton.comDILM, DILA, DILE, DILH
Engineering
The diagrams show the closing and opening travel of the contacts at no load.
N/O
NC
x1
x2
DILE AC
N/O
1.9
2.8
NC
0.95
2.8
…
DILE
N/O
1.9
2.8
NC
0.9
2.8
…
DDILE
NO early-make
1.06
2.9
Late-break N/C contact
1.86
2.9
N/O
1.9
2.8
NC
0.9
2.8
DILE DC
N/O
1.9
2.85
NC
0.95
2.85
DILE…
N/O
1.9
2.8
NC
0.9
2.8
…
DDILE
NO early-make
1.06
2.9
Late-break N/C contact
1.86
2.9
N/O
1.9
2.8
NC
0.9
2.8
DILA-AC
N/O
3.3
4.5
NC
1.0
4.5
DILA-XHI
N/O
3.2
4.5
NC
1.6
4.5
DILA-XHIV
NO early-make
2.0
4.5
Late-break N/C contact
2.8
4.5
N/O
3.2
4.5
NC
1.6
4.5
DILA-DC
N/O
2.1
2.9
NC
0.7
2.9
DILA-XHI
N/O
2.3
2.9
NC
0.7
2.9
DILA-XHIV
NO early-make
1.1
2.9
Late-break N/C contact
1.9
2.9
N/O
2.3
2.9
NC
0.7
2.9
DILM7/9 AC
N/O
3.3
4.5
NC
1.0
4.5
DILM32-XHI, DILA-XHI
N/O
3.2
4.5
NC
1.6
4.5
DILA-XHIV
NO early-make
2.0
4.5
Late-break N/C contact
2.8
4.5
N/O
3.2
4.5
NC
1.6
4.5
DILM7/9 DC
N/O
2.1
2.9
NC
0.7
2.9
DILM32-XHI, DILA-XHI
N/O
2.3
2.9
NC
0.7
2.9
DILA-XHIV
NO early-make
1.1
2.9
Late-break N/C contact
1.9
2.9
N/O
2.3
2.9
NC
0.7
2.9
DILM12/15/P20 AC
N/O
3.3
4.5
NC
1.0
4.5
DILM32-XHI, DILA-XHI
N/O
3.2
4.5
NC
1.6
4.5
DILA-XHIV
NO early-make
2.0
4.5
Late-break N/C contact
2.8
4.5
N/O
3.2
4.5
NC
1.6
4.5
DILM12/15/P20 DC
N/O
3.3
4.4
NC
1.0
4.4
DILM32-XHI, DILA-XHI
N/O
3.2
4.4
NC
1.6
4.4
x
2
x
2
x
1
0
0
x
1
DILA-XHIV
NO early-make
2.0
4.4
Late-break N/C contact
2.8
4.4
N/O
3.2
4.4
NC
1.6
4.4
DILM17/25/32/P32/P45
N/O
4.0
6.0
Auxiliary N/C
1.8
6.0
Auxiliary N/O
3.2
6.0
DILM32-XHI, DILA-XHI
N/O
3.2
6.0
NC
1.6
6.0
DILA-XHIV
NO early-make
2.0
6.0
Late-break N/C contact
2.8
6.0
N/O
3.2
6.0
NC
1.6
6.0
DILM40/50/65/P63/P80
N/O
5.1
7.5
DILM150-XHI
N/O
5.7
7.5
NC
3.9
7.5
DILM150-XHIV
NO early-make
3.8
7.5
Late-break N/C contact
5.4
7.5
N/O
5.7
7.5
NC
3.9
7.5
DILM1000-XHI
N/O
5.5
7.5
NC
3.6
7.5
DILM1000-XHIV
NO early-make
4.1
7.5
Late-break N/C contact
5.0
7.5
DILM80/95/115/150/170/P125/P160/P200
N/O
8.0
11
DILM150-XHI
N/O
9.2
11
NC
7.4
11
DILM150-XHIV
NO early-make
7.3
11
Late-break N/C contact
8.9
11
N/O
9.2
11
NC
7.4
11
DILM1000-XHI
N/O
9.0
11
NC
7.1
11
DILM1000-XHIV
NO early-make
7.6
11
Late-break N/C contact
8.5
11
DILM185A/225A
N/O
10.0
13.0
DILM1000-XHI
N/O
10.0
13.0
NC
8.1
13.0
DILM1000-XHIV
NO early-make
8.4
13.0
Late-break N/C contact
9.5
13.0
DILM250/300A
N/O
10.1
13.1
DILM820-XHI
N/O
10.3
13.1
NC
8.4
13.1
DILM820-XHIV
NO early-make
8.7
13.1
Late-break N/C contact
9.8
13.1
DILM400/500/570
N/O
8.9
13.1
DILM820-XHI
N/O
10.3
13.1
NC
8.4
13.1
DILM820-XHIV
NO early-make
8.7
13.1
Late-break N/C contact
9.8
13.1
DILM580/650/750/820
N/O
2.0
4.1
DILM820-XHI
N/O
7.4
10.5
NC
5.5
10.5
DILM820-XHIV
NO early-make
6.0
10.5
Late-break N/C contact
6.8
10.5
DILM1000/1600, DILH1400/2000/2200/2600
N/O
2.0
4.1
DILM820-XHI
N/O
7.4
10.5
NC
5.5
10.5
DILM820-XHIV
NO early-make
6.0
10.5
Late-break N/C contact
6.8
10.5
The diagrams show the closing and opening travel of the contacts at no load.
N/O
NC
x1
x2
x
2
x
2
x
1
0
0
x
1
