5/86 Contactors
UL/CSA Short circuit current rating
2010 CA08103002Z-EN
for North America
Short circuit current rating (SCCR)
Contactor Basic Rating 480 V High Fault 600 V High Fault
Max. fuse Max. CB Max. fuse Max. CB Max. fuse Max. CB
kA A A kA A kA A kA A kA A
DILM7-…(…) 5 45 60 100 20 Class J - Fuse only 30 25 - Fuse only
DILM9-…(…) 5 45 60 100 20 Class J - Fuse only 30 25 - Fuse only
DILM12-…(…) 5 45 60 100 20 Class J - Fuse only 30 25 - Fuse only
DILM15-…(…) 5 45 60 100 20 Class J - Fuse only 30 25 - Fuse only
DILM17-…(…) 5 125 125 100 70 Class J 10 50 10 125 10 50
DILM25-…(…) 5 125 125 100 100 Class J 10 50 10 125 10 50
DILM32-…(…) 5 125 125 100 125 Class J 10 50 10 125 10 50
DILM38-…(…) 5 125 125 100 125 Class J 10 50 10 125 10 50
DILM40(…) 10 250 250 100 150 Class J 65 100 30 250 30 250
DILM50(…) 10 250 250 100 150 Class J 65 100 30 250 30 250
DILM65(…) 10 250 250 100 150 Class J 65 100 30 250 30 250
DILM72(…) 10 250 250 100 150 Class J 65 100 30 250 30 250
DILM80(…) 10 600 600 100 300 Class J 65 250 30 300 30 350
DILM95(…) 10 600 600 100 300 Class J 65 250 30 300 30 350
DILM115(…) 10 600 600 100 300 Class J 65 250 30 300 30 350
DILM150(…) 10 600 600 100 300 Class J 65 250 30 300 30 350
DILM170(…) 10 600 600 100 300 Class J 65 250 30 300 30 350
DILM185(…) 18 700 600 - CB only 65 250 - - - -
DILM225(…) 18 700 600 - CB only 65 250 - - - -
DILM250(…) 18 700 600 - CB only 65 250 - - - -
DILM300(…) 30 800 600 - CB only 42 600 30 800 30 600
DILM400(…) 30 800 600 - CB only 42 600 30 800 30 600
DILM500(…) 30 800 600 - CB only 42 600 30 800 30 600
DILM570(…) 30 800 600 - CB only 42 600 30 800 30 600
DILM580(…) 30 2000 1200 85 2000 85 1200 85 2000 85 1200
DILM650(…) 30 2000 1200 85 2000 85 1200 85 2000 85 1200
DILM750(…) 42 2000 1200 85 2000 85 1200 85 2000 85 1200
DILM820(…) 42 2000 1200 85 2000 85 1200 85 2000 85 1200
DILM1000(…) 85 2000 1200 85 2000 85 1200 85 2000 85 1200
DILM1600(…) 85 2000 - 85 2000 - - 85 2000 85 -
DILM
