Contactors
UL/CSA Special purpose rating
2010
CA08103002Z-EN
www.eaton.comfor North America
5/85
forNorthAmericaUL/CSASpecialpurpose rating
forNorthAmericaUL/CSAShortcircuitcurrent rating
Special purpose rating
DIL M7
M9 M12 M15 M17 M25 M32 M40 M50 M65 M80 M95 M115 M150
MP32
MP63 MP80 M72 MP125 MP160
M170
MP45
MP200
Electrical discharge lamps
(
ballast)
480
V 60Hz 3phase, 277V
60
Hz 1phase
A 12
18
20
20
27
35
40
63
79
88
85
100
136 160
600
V 60Hz 3phase, 347V
60
Hz 1phase
A 12
18
20
20
27
35
40
63
79
88
85
100
136 160
Incandescent lamps
(
Tungsten)
480
V 60Hz 3phase, 277V
60
Hz 1phase
A 8
11
14
14
23
32
40
55
74
88
85
100
136 160
600
V 60Hz 3phase, 347V
60
Hz 1phase
A 8
11
14
14
23
32
40
55
74
88
85
100
136 160
Resistance air heating
480
V60Hz 3phase,
277
V60Hz 1phase
A 12
18
20
20
27
35
40
63
79
88
94
110
136 160
600
V60Hz 3phase,
347
V60Hz 1phase
A 12
18
20
20
27
35
40
63
79
88
94
110
136 160
Refrigeration control
(
CSA only)
LRA 480V 60Hz 3phase
A 60
60
60
60
240 240 240 270
270
270 540
540
540 540
LRA 600V 60Hz 3phase
A 60
60
60
60
180 180 180 270
270
270 420
420
540 540
480
V 60Hz 3phase
A 6
7.5 10
10
23
32
40
26
36
45
63
70
84
90
600
V 60Hz 3phase
A 6
7.5 10
10
17
24
30
26
36
45
63
70
84
90
Elevator control
200
V 60Hz 3phase
HP (A) ¾ (3.7) 2 (7.8) 2 (7.8) 2 (7.8) 3 (11) 3 (11) 7½
(25.3)
7½
(25.3)
10
(32.2)
10
(32.2)
20
(62.1)
20
(62.1)
30 (92) 30 (92)
240
V 60Hz 3phase
HP (A) 1½ (6.0) 2 (6.8) 2 (6.8) 3 (9.6) 3 (9.6) 5
(15.2)
7½
(22)
10 (28) 15 (42) 15 (42) 25 (68) 30 (80) 40
(104)
40 (104)
480
V 60Hz 3phase
HP (A) 2 (3.4)
3 (4.8) 7½
(11)
7½
(11)
7½
(11)
10 (14) 20 (27) 25 (34) 30 (40) 30 (40) 50 (65) 60 (77) 75 (96) 75 (96)
600
V 60Hz 3phase
HP (A) 3 (3.9)
5 (6.1) 7½
(9.6)
7½
(9.6)
10 (11) 15 (17) 20 (22) 30 (32) 40 (41) 40 (41) 60 (62) 75 (77) 100
(99)
100 (99)
DIL K12
K20 K25 K33 K50
Capacitor Switching
240
V 60Hz 3phase
A 18
28
36
48
72
480
V 60Hz 3phase
A 18
28
36
48
72
600
V 60Hz 3phase
A 14.4
28
38.4 48
72
240
V 60Hz 3phase
kvar 7.5
12
15
20
30
480
V 60Hz 3phase
kvar 15
20
30
40
60
600
V 60Hz 3phase
kvar 15
30
40
50
75
DILM, DILMP, DILK
