Frequency inverters
Assigned switching and protective elements
Motor connection
Short-circuit and
cable protection
(fuse)
Mains contactor Mains contactor with
parallel connector
(main current-
paths)3)
Mains choke Radio interference
suppression filters
(only for part nos.
MMX…N…)
Motor chokes Sine-wave filters
– DILM7 DILEM+P1DILEM DEX-LN1-006 MMX-LZ1-009 DEX-LM3-005 SFB400/4
– DILM7 DILEM+P1DILEM DEX-LN1-006 MMX-LZ1-009 DEX-LM3-005 SFB400/4
– DILM7 DILEM+P1DILEM DEX-LN1-009 MMX-LZ1-009 DEX-LM3-005 SFB400/4
– DILM7 DILEM+P1DILEM DEX-LN1-009 MMX-LZ1-009 DEX-LM3-005 SFB400/4
– DILM7 – DEX-LN1-013 MMX-LZ1-015 DEX-LM3-005 SFB400/10
– DILM7 – DEX-LN1-018 MMX-LZ1-015 DEX-LM3-008 SFB400/10
– DILM7 – DEX-LN1-018 MMX-LZ1-017 DEX-LM3-011 SFB400/10
PKM0-6,3 DILEM – DEX-LN3-004 MMX-LZ3-006 DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM – DEX-LN3-004 MMX-LZ3-006 DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM – DEX-LN3-004 MMX-LZ3-006 DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM – DEX-LN3-006 MMX-LZ3-006 DEX-LM3-005 SFB400/4
PKM0-10 DILEM – DEX-LN3-010 MMX-LZ3-009 DEX-LM3-005 SFB400/10
PKM0-10 DILEM – DEX-LN3-010 MMX-LZ3-009 DEX-LM3-008 SFB400/10
PKM0-20 DILM7 – DEX-LN3-016 MMX-LZ3-020 DEX-LM3-011 SFB400/10
PKM0-6,3 DILEM – DEX-LN3-004 MMX-LZ3-006 DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM – DEX-LN3-004 MMX-LZ3-006 DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM – DEX-LN3-004 MMX-LZ3-006 DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM – DEX-LN3-006 MMX-LZ3-006 DEX-LM3-005 SFB400/4
PKM0-10 DILEM – DEX-LN3-006 MMX-LZ3-009 DEX-LM3-005 SFB400/4
PKM0-10 DILEM – DEX-LN3-010 MMX-LZ3-009 DEX-LM3-008 SFB400/10
PKM0-20 DILEM – DEX-LN3-010 MMX-LZ3-020 DEX-LM3-008 SFB400/10
PKM0-20 DILM7 – DEX-LN3-016 MMX-LZ3-020 DEX-LM3-011 SFB400/10
PKM0-20 DILM7 – DEX-LN3-016 MMX-LZ3-020 DEX-LM3-016 SFB400/16.5
PKM0-25 DILM7 – DEX-LN3-016 MMX-LZ3-020 DEX-LM3-016 SFB400/16.5
10/29
M-Max™
