Frequency inverters
Assigned switching and protective elements
Assigned switchingandprotectiveelements
Mains supply Motor connection
Short-circuit and line
protection (fuse)2) Mains contactor Motor chokes Sine-wave filters
PKM0-6,3 DILEM DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM DEX-LM3-005 SFB400/4
PKM0-10 DILEM DEX-LM3-008 SFB400/10
PKM0-10 DILEM DEX-LM3-008 SFB400/10
PKM0-16 DILM7 DEX-LM3-011 SFB400/16.5
PKM0-16 DILM7 DEX-LM3-016 SFB400/16.5
PKM0-25 DILM7 DEX-LM3-035 SFB400/32
PKM0-32 DILM17 DEX-LM3-035 SFB400/32
PKM4-40 DILM17 DEX-LM3-035 SFB400/32
PKM4-50 DILM40 DEX-LM3-050 SFB400/48
PKM4-63 DILM50 DEX-LM3-063 SFB400/115
NZM...1-A80 DILM65 DEX-LM3-080 SFB400/115
NZM...1-A100 DILM80 DEX-LM3-100 SFB400/115
NZM...1-A125 DILM95 DEX-LM3-1002) SFB400/115
NZM...1-A160 DILM150 DEX-LM3-150 SFB400/150
NZM...2-A200 DILM170 DEX-LM3-180 SFB400/180
NZM...2-A250 DILM185 DEX-LM3-220 SFB400/250
NZM...3-AE400 DILM185 DEX-LM3-260 SFB400/440
NZM...3-AE400 DILM250 Please enquire SFB400/440
PKM0-6,3 DILEM DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM DEX-LM3-005 SFB400/4
PKM0-6,3 DILEM DEX-LM3-008 SFB400/10
PKM0-10 DILEM DEX-LM3-008 SFB400/10
PKM0-10 DILEM DEX-LM3-011 SFB400/10
PKM0-16 DILM7 DEX-LM3-016 SFB400/16.5
PKM0-16 DILM7 DEX-LM3-016 SFB400/16.5
PKM0-25 DILM7 DEX-LM3-035 SFB400/23.5
PKM0-32 DILM17 DEX-LM3-035 SFB400/32
PKM4-40 DILM17 DEX-LM3-050 SFB400/37
PKM4-50 DILM40 DEX-LM3-050 SFB400/48
PKM4-63 DILM50 DEX-LM3-063 SFB400/115
NZM...1-A80 DILM65 DEX-LM3-080 SFB400/115
NZM...1-A100 DILM80 DEX-LM3-100 SFB400/115
NZM...1-A125 DILM95 DEX-LM3-1002) SFB400/115
NZM...1-A160 DILM150 DEX-LM3-150 SFB400/150
NZM...2-A200 DILM170 DEX-LM3-180 SFB400/180
NZM...2-A250 DILM185 DEX-LM3-220 SFB400/250
NZM...3-AE400 DILM185 DEX-LM3-260 SFB400/440
NZM...3-AE400 DILM250 Please enquire SFB400/440
